Nexperia Medium Power Low VF Schottky Diode 60 V 6.3 A, 2-Pin SOD-128 PMEG6045ETPX
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 4mm |
| Model | PMEG6045ETPX |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | PMEG6045ETP |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-128 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 6.3A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 300mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 70A |
| Maximum Forward Voltage Vf | 530mV |
| Peak Reverse Recovery Time trr | 20ns |
| Average forward current | IF(AV) ≤ 4.5 A |
| Reverse voltage | VR ≤ 60 V |
Key Features
- Maximum continuous forward current of 6.3 A ensures reliable operation under moderate load conditions.
- Peak reverse repetitive voltage rated at 60 V for effective blocking capabilities.
- Low forward voltage drop of 530 mV for efficient power conversion.
- High maximum operating temperature up to 175°C supports demanding applications.
- Surface-mount design in a compact SOD-128 package minimizes PCB space.
- Public automotive standard AEC-Q101 qualification guarantees robustness.
- Peak non-repetitive forward surge current up to 70 A for transient load handling.
- Fast peak reverse recovery time of 20 ns improves switching performance.
Product Description
Nexperia PMEG6045ETPX is a medium power Schottky diode designed for efficient and reliable rectification in electronic circuits. It features a voltage rating of 60 V and a maximum continuous forward current of 6.3 A, encapsulated within a SOD-128 surface-mount package with 2 pins.
This diode offers a low forward voltage of 530 mV, enabling improved power efficiency and reduced heat dissipation. Its compact, flat lead SMD plastic package promotes space-saving board layout, ideal for modern electronic applications.
The integrated guard ring enhances durability by protecting against electrical stress, while the device supports high temperature operation up to 175°C, making it suitable for automotive and industrial environments adhering to the AEC-Q101 standard.
Featuring a peak non-repetitive forward surge current of 70 A and a rapid peak reverse recovery time of 20 ns, the PMEG6045ETPX is well-suited for high-speed switching and power management use cases.
This Schottky diode is commonly used in power supplies, battery management circuits, and other electronic applications where low forward voltage and fast switching are critical. Maximum continuous forward current of 6.3 A ensures reliable operation under moderate load conditions.
Peak reverse repetitive voltage rated at 60 V for effective blocking capabilities. Low forward voltage drop of 530 mV for efficient power conversion. High maximum operating temperature up to 175°C supports demanding applications.
Surface-mount design in a compact SOD-128 package minimizes PCB space. Public automotive standard AEC-Q101 qualification guarantees robustness. Peak non-repetitive forward surge current up to 70 A for transient load handling.
Fast peak reverse recovery time of 20 ns improves switching performance. Integrated guard ring ensures protection against electrical stress. Explore additional Nexperia semiconductor components and Schottky diodes on EnvMart for enhanced electronic circuit design solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the PMEG6045ETPX is 6.3 A, ensuring reliable operation under moderate load conditions.
This model has a peak reverse repetitive voltage rating of 60 V, providing effective blocking capabilities.
The forward voltage drop is 530 mV, which aids in efficient power conversion and reduced heat dissipation.
The maximum operating temperature is 175°C, making it suitable for demanding applications.
It is encapsulated in a compact SOD-128 surface-mount package, which minimizes PCB space.
The PMEG6045ETPX complies with the AEC-Q101 automotive standard, ensuring robustness for automotive applications.
The peak non-repetitive forward surge current is rated at 70 A, allowing it to handle transient loads effectively.
The peak reverse recovery time is 20 ns, which enhances its switching performance.
The dimensions of this diode are 4 mm in length, 2.7 mm in width, and 1.1 mm in height.
The minimum operating temperature is -55°C, allowing it to function in low-temperature environments.
The PMEG6045ETPX features a single diode configuration, suitable for various electronic applications.
The average forward current rating is IF(AV) ≤ 4.5 A, indicating its capability under average load conditions.
