Nexperia Medium Power 1 A NPN Bipolar Transistor 80 V 3-Pin SOT-223 Package BCP56-10TX

Nexperia BCP56-10TX is a medium power NPN bipolar transistor designed for switching and amplification with a maximum collector current of 1 A and collector emitter voltage rating of 80 V. Packaged in a compact 3-pin SOT-223 surface-mount device, this transistor delivers reliable performance in a small footprint.

This transistor features a maximum power dissipation of 1.35 W and a high transition frequency of up to 180 MHz, making it suitable for fast switching applications in industrial and electronic use cases. The device operates efficiently over a wide temperature range from -55°C to 150°C and meets RoHS environmental standards and the automotive qualification AEC-Q101, ensuring compliance with quality and reliability standards.

The compact dimensions (length 6.5 mm, width 3.5 mm, height 1.65 mm) support space-saving electronics design. Its minimum DC current gain (hFE) of 63 enables effective amplification in circuits. The device's surface-mount SOT-223 package facilitates easy PCB integration and robust mechanical mounting.

This Nexperia BCP56-10TX transistor is ideal for applications requiring medium power handling with efficient switching and amplification capabilities, including automotive, manufacturing, HVAC, and industrial electronic systems.

The transistor features a maximum power dissipation of 1.35 W for reliable performance. It has a minimum DC current gain (hFE) of 63, suitable for amplification applications. Operating temperature ranges from -55°C to 150°C for versatility in various environments.

The package is surface-mount type SOT-223 with compact dimensions of 6.5 mm length and 3.5 mm width. It complies with RoHS standards and meets automotive AEC-Q101 qualification. Provides high-frequency operation with a maximum transition frequency of 180 MHz.

Lowest emitter base voltage is 5 V, enabling efficient transistor switching. Suitable for switching and amplification applications in electronic circuits. Compact and space-saving design ideal for medium power applications.
