Hirose DF3 Series Straight Through Hole PCB Header, 12 Contact(s), 2 mm Pitch, 1 Row, Shrouded DF3A-12P-2DSA

Free Delivery in India | Lowest Global Shipping Charges

Hirose DF3 Series Straight Through Hole PCB Header, 12 Contact(s), 2 mm Pitch, 1 Row, Shrouded DF3A-12P-2DSA

Name: Hirose DF3 Series Straight Through Hole PCB Header, 12 Contact(s), 2 mm Pitch, 1 Row, Shrouded DF3A-12P-2DSA
Brand: Hirose
SKU: 214836



Category PCB Header Brand Hirose Condition New

Specifications

Country of Origin	Japan
Voltage	250V
Brand	Hirose
Orientation	Straight
Current	3A
Model	DF3A-12P-2DSA
Mount Type	Through Hole
Housing Material	Polyamide
Contact Material	Copper Alloy
Series	DF3
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-30°C
Number of Rows	1
Pitch	2mm
Contact Plating	Tin
Number of Contacts	12
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board

Key Features

Supports a current rating of 3A for robust electrical performance.
Constructed with polyamide housing for durability and heat resistance.
Copper alloy contacts plated with tin ensure efficient conductivity and corrosion resistance.
Designed for through hole mounting with a 0.8 mm board through-hole diameter.
Operating temperature range from -30°C to 85°C for versatile applications.
Single row, straight orientation with a 2 mm row pitch for standard PCB layouts.
Shrouded male contact gender provides secure and safe connections.
Connector system compatible with both board-to-board and wire-to-board configurations.

Product Description

The Hirose DF3 Series Straight Through Hole PCB Header, model DF3A-12P-2DSA, features 12 male copper alloy contacts arranged in a single row with 2 mm pitch.

This shrouded PCB header provides a reliable and compact connection solution for electronic assembly requiring board-to-board or wire-to-board integration. Its polyamide housing offers excellent mechanical strength and thermal stability, making it suitable for a wide range of industrial and commercial electronic applications.

With a current rating of 3A and voltage rating of 250V, this connector supports moderate power applications while maintaining connection integrity. The tin plated contacts ensure corrosion resistance and preserve long-term conductivity.

Designed for through hole mounting on PCBs with 0.8 mm hole diameter, the straight orientation and single row form factor facilitate easy placement and soldering onto circuit boards. Its operating temperature range from -30°C to 85°C allows deployment in various climates and operational environments including industrial controls, instrumentation, and telecommunications equipment.

Current rating of 3A for reliable electrical performance. Polyamide housing offering durability and heat resistance. Copper alloy contacts with tin plating for corrosion protection. Through hole mount type with 0.8 mm board hole diameter.

Operating temperature range: -30°C to 85°C. Voltage rating of 250V suitable for diverse applications. Single row, 2 mm pitch, straight orientation. Shrouded design enhances connection security. Compatible with board-to-board and wire-to-board systems.

Solder termination ensures stable connections.

This PCB Header from Hirose is ideal for manufacturers and engineers designing and assembling electronic devices in industrial, laboratory, and commercial sectors. Its robust construction and precise performance specifications comply with demanding operational requirements.
