JAE IL-AG5 Series Right Angle Through Hole PCB Header 6 Contact 2.5 mm Pitch 1 Row Shrouded IL-AG5-6P-S3L2

JAE IL-AG5-6P-S3L2 is a right angle through hole PCB header belonging to the IL-AG5 series, designed to provide reliable connections in automotive and industrial electronic assemblies. This product features 6 male contacts arranged in a single row with a 2.5 mm pitch, housed in a shrouded polybutylene terephthalate material that offers durability and electrical insulation.

Rated at 3 amperes, the contacts are made of brass with tin plating to ensure strong conductivity and resistance to corrosion. The right angle orientation facilitates compact PCB layouts and effective wire-to-board connections. This header is mounted by through hole technique with solder termination, providing robust mechanical and electrical performance.

Operating temperatures range from -40°C to 85°C, making this connector suitable for harsh environments and automotive instrument panel applications. The connector features a mechanical lock and a double locking mechanism that prevents accidental dislodgment of contacts, enhancing operational reliability. Additionally, a polarized version is available for the 5 and 6 contact single row types to avoid mismatching during assembly.

The design and construction of the IL-AG5 series headers are intended for industrial, automotive, electronics manufacturing, and PCB assembly use cases, providing a reliable and standard connector solution. The product is compliant with no specific standards but is engineered for high performance and durability in industrial environments.

Designed for automotive instrument panel applications ensuring reliability. Housing made from durable polybutylene terephthalate material. Current rating up to 3A suitable for moderate electrical loads. Male brass contacts with tin plating provide excellent conductivity.

Right angle orientation for optimal PCB connection. Through hole mount type for secure soldered termination. Supports operating temperature range from -40°C to 85°C. Mechanical double lock system prevents dislodging of contacts.

Polarized version availability prevents mismating for 5 and 6 contact single row variants. Wire-to-board connector system ensures compatibility with various PCB designs.
