onsemi Operational Amplifier 4.5 MHz Gain Bandwidth Product, 8-Pin SOIC Surface Mount Package MC33072DR2G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Operational Amplifier 4.5 MHz Gain Bandwidth Product, 8-Pin SOIC Surface Mount Package MC33072DR2G

Name: onsemi Operational Amplifier 4.5 MHz Gain Bandwidth Product, 8-Pin SOIC Surface Mount Package MC33072DR2G
Brand: onsemi
SKU: 212519
Price: 0.32 USD
Availability: InStock



Category Operational Amplifier Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	5mm
Model	MC33072DR2G
Width	4mm
Mount Type	Surface
Series	MC33072
Output Current	30mA
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Number Of Channels	2
Standards/Approvals	RoHS
Pin Count	8
Automotive Standard	AEC-Q100
Maximum Supply Voltage	44V
Minimum Supply Voltage	5V
GBP - Gain Bandwidth Product	4.5MHz
Input Bias Current	500 nA
Vos - Input Offset Voltage	5 mV
Slew Rate	13V/μs
Low input offset voltage	3 mV Max. (A Suffix)
Input Offset Current	75 nA
Low Total Harmonic Distortion	0.02%
Large Output Voltage Swing	-14.7 V to +14 V (with ±15 V Supplies)
Fast Settling Time	1.1 μs to 0.1%
Wide Single Supply Operation	3 V to 44 V
Large Capacitance Drive Capability	0 pF to 10000 pF
Excellent Gain Margin	12 dB

Key Features

Features dual-channel configuration suitable for versatile applications.
Supported voltage range from 3 V to 44 V allows wide operating conditions.
Fast slew rate of 13 V/μs ensures rapid response times.
Low input offset voltage and bias current improve precision and reduce errors.
Supports surface mount technology with compact SOIC package.
RoHS compliant design aligns with environmental standards.
AEC-Q100 qualified for automotive industry reliability standards.
Wide operating temperature range from -40°C to 85°C ensures durability in harsh environments.

Product Description

The onsemi MC33072DR2G is a dual-channel operational amplifier featuring a gain bandwidth product of 4.5 MHz housed in an 8-Pin SOIC surface mount package. Designed to serve a wide array of amplification needs in industrial, automotive, and consumer electronics, this device offers reliable performance with a supply voltage capability spanning from 3 V to as high as 44 V.

This operational amplifier delivers fast response characteristics with a slew rate of 13 V/μs, making it ideal for applications requiring quick signal transitions. It exhibits low input offset voltage of 5 mV and bias current limited to 500 nA, supporting precision amplification tasks with minimal error introduction.

The MC33072DR2G supports surface mount technology with a compact and efficient package size (5 mm length × 4 mm width × 1.5 mm height). It is qualified for automotive applications under the AEC-Q100 standard, reflecting a robust design suitable for harsh temperature and operational conditions ranging from -40°C to 85°C.

Additional features include output current capability up to 30 mA, wide input common mode voltage range including ground potential, and large output voltage swing, enabling versatile use in analog signal processing circuits and control systems. Its RoHS compliance ensures minimal environmental impact during manufacture and disposal.

Dual-channel operational amplifier with 4.5 MHz gain bandwidth product. Wide supply voltage range: 3 V to 44 V for versatile applications. Low input offset voltage and input bias current for precision signal amplification.

AEC-Q100 qualified for automotive reliability. Compact 8-Pin SOIC surface mount package. High slew rate of 13 V/μs for fast signal response. Wide operating temperature range from -40°C to 85°C. RoHS compliant design supports environmental standards.

This Operational Amplifier is suitable for electronic components in industrial control systems, automotive electronics, consumer audio devices, and laboratory equipment where precise and reliable amplification is required. Explore the broad onsemi portfolio and other semiconductor devices on EnvMart for comprehensive solutions in electronic design and manufacturing.
