Vishay MKP 338 Film Capacitor X1, ±20 %, 2.2 nF, 1000 V dc, 440 V ac, Through Hole BFC233860222

Free Delivery in India | Lowest Global Shipping Charges

Vishay MKP 338 Film Capacitor X1, ±20 %, 2.2 nF, 1000 V dc, 440 V ac, Through Hole BFC233860222

Name: Vishay MKP 338 Film Capacitor X1, ±20 %, 2.2 nF, 1000 V dc, 440 V ac, Through Hole BFC233860222
Brand: Vishay
SKU: 211297
Price: 1.15 USD
Availability: InStock



Category Film Capacitor Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	9mm
Length	10mm
Model	BFC233860222
Width	4mm
Mount Type	Through Hole
Series	MKP 338
Maximum Operating Temperature	105°C
Tolerance	±20 %
Capacitance	2.2nF
Minimum Operating Temperature	-55°C
Terminal type	Solder
Lead Length	3.5mm
Package/Case	Plastic
Pin Count	2
Rated AC Voltage	440V ac
Rated DC Voltage	1000V dc
Lead Pitch	7.5mm
Lead Diameter	0.5mm
Dielectric	Polypropylene
Suppression Class	X1

Key Features

The capacitor features polypropylene dielectric material for high reliability.
It has a rated AC voltage of 440 volts and a DC voltage rating of 1000 volts.
The product has a tolerance of ±20 % ensuring consistent capacitance values.
It is equipped with a plastic case and flame-retardant epoxy sealing.
Lead pitch measures 7.5 mm with lead length of 3.5 mm and 0.5 mm lead diameter.
The capacitor is designed to operate reliably between -55°C and 105°C.
It is a through hole mount type with two pins and solder terminals for easy PCB installation.

Product Description

Vishay BFC233860222 is a MKP 338 series film capacitor categorized as type X1, engineered for suppression applications with a capacitance of 2.2 nF, ±20 % tolerance. It is designed for use across both DC and AC voltage ranges, rated at 1000 V dc and 440 V ac respectively, providing reliable performance in industrial, electrical, and electronic equipment.

The capacitor employs polypropylene dielectric to ensure self-healing properties and exceptional electrical characteristics. Its plastic case conforms to UL 94 V-0 flame-retardant standards, with epoxy sealing resin enhancing safety and durability in harsh environments.

With precise dimensions of length 10 mm, width 4 mm, and height 9 mm, and a lead pitch of 7.5 mm with 3.5 mm lead length and 0.5 mm lead diameter, it supports through hole PCB mounting suitable for various assembly processes.

This device is built to operate effectively in temperatures ranging from -55°C up to 105°C and complies with key international standards EN 60384-14:2013, IEC 60065, and UL certifications, making it suitable for use in industrial electronics, power supplies, consumer electronics, HVAC controls, and suppression applications where safety and reliability are critical.

The capacitor features polypropylene dielectric material for high reliability. It has a rated AC voltage of 440 volts and a DC voltage rating of 1000 volts. The product has a tolerance of ±20 % ensuring consistent capacitance values.

It is equipped with a plastic case and flame-retardant epoxy sealing. Dimensions include a length of 10 mm, width of 4 mm, and height of 9 mm. Lead pitch measures 7.5 mm with lead length of 3.5 mm and 0.5 mm lead diameter.

The capacitor is designed to operate reliably between -55°C and 105°C. Standards compliance includes EN 60384-14:2013, IEC 60065, UL 60384-14, and IEC 60384-14:2013. It is a through hole mount type with two pins and solder terminals for easy PCB installation.

This Vishay MKP 338 film capacitor is ideal for use in electronics manufacturing, industrial equipment maintenance, and other sectors requiring high-quality, safety-rated film capacitors for voltage suppression and signal filtering. Browse the Electronics Components category at EnvMart for more Vishay Film Capacitors and related passive components.
