Wurth Elektronik 1 mm Pitch 6 Way Horizontal Female Surface Mount FPC Connector 686106183522

Wurth Elektronik 686106183522 is a 6 way horizontal female FPC connector with a 1.0 mm pitch and surface mount termination type. This connector belongs to the WR-FPC series, featuring a low profile height of 1.2 mm optimized for high-density electronic applications.

The connector utilizes a Zero Insertion Force (ZIF) flip lock actuator mechanism, allowing easy and secure insertion of flexible printed circuit (FPC) cables while providing high retention force. Phosphor bronze contacts plated with tin over nickel ensure stable electrical connections with a current rating of 800mA and voltage rating of 50V AC.

Constructed with liquid crystal polymer housing for robust durability, this FPC connector supports one row of contacts in a bottom contact position and horizontal orientation. Its operating temperature ranges from -25°C to 85°C, making it suitable for varied environmental conditions.

Additional features include brass solder tabs on both sides for enhanced mechanical stability when mounted on PCBs. The WR-FPC series connectors are ideal for applications in consumer electronics such as personal computers, tablets, mobile phones, cameras, as well as industrial, business, and medical electronic equipment.

Low profile, space-saving design with 1.2 mm height. Flip lock actuator enables easy and reliable FPC cable insertion. Phosphor bronze contacts with tin over nickel plating for durability. Current rating of 800mA and voltage rating of 50V AC.

Liquid crystal polymer housing material for mechanical strength. Solder tabs on either side for secure PCB attachment. Bottom contact position with horizontal orientation. Temperature range from -25°C to 85°C for diverse applications.

This Wurth Elektronik FPC Connector is an excellent choice for designers seeking reliable, compact connectors for miniaturized high-density electronic systems, including displays, touch panels, screens, and various consumer and medical electronics devices.
