Wurth Elektronik WR-FPC 1 mm Pitch 4 Way Horizontal Female FPC Connector Surface Mount 686104183422

Wurth Elektronik 686104183422 is a 4 Way Horizontal Female FPC Connector with a 1 mm pitch, designed as a surface mount component for high density PCB applications. This WR-FPC series connector features a low profile height of just 1.2 mm, making it ideal for compact electronics assemblies.

The connector includes a flip lock ZIF (Zero Insertion Force) actuator that facilitates easy FPC insertion and provides superior retention strength, ensuring reliable mechanical and electrical connections under demanding conditions. The phosphor bronze contact material plated with tin over nickel offers excellent conductivity and corrosion resistance. The housing is made from liquid crystal polymer, which gives high dimensional stability and durability.

Rated for 800 mA current and 50V ac voltage, this connector supports a broad range of miniaturized applications including displays, touch panels, screens, consumer electronics like tablets and mobile phones, as well as industrial, medical, and business equipment. The operating temperature range of -25°C to 85°C further extends its applicability in various environmental conditions.

Additional features include solder tabs on either side for secure attachment to the PCB, a locking mechanism for robust FPC retention, and top contact design with horizontal orientation for design flexibility. This component can accommodate top or bottom contact styles depending on design requirements.

Features a 1 mm pitch with 4 female contacts for reliable connectivity. Constructed with phosphor bronze contacts plated with tin over nickel for durability. Surface mount with top contact position and horizontal orientation.

Incorporates a flip lock ZIF actuator for easy FPC insertion and secure retention. Operates safely at up to 50V ac with a current rating of 800 mA. Housing made of liquid crystal polymer providing high mechanical strength.

Suitable for use in miniaturized, high density applications such as displays and consumer electronics. Operating temperature ranging from -25°C to 85°C ensuring reliability in diverse environments. Includes locking mechanism and solder tabs for enhanced PCB attachment and mechanical stability.

This Wurth Elektronik WR-FPC connector series is a reliable choice for electronic product designers and manufacturers seeking low profile connectors for demanding compact applications. Explore more FPC Connectors and electronic components in the EnvMart catalog to find ideal matches for your projects.
