TDK Standard Metal Oxide Varistor 460pF 100A Clamping Current 2970V Varistor Voltage 820V B72220S0511K101
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 10mm |
| Brand | TDK |
| Material | Metal |
| THICKNESS | 7.1mm |
| Length | 21.5mm |
| Model | B72220S0511K101 |
| Depth | 26mm |
| Mount Type | Lead |
| Series | Standard |
| Energy Rating | 1J |
| Maximum Operating Temperature | 105°C |
| Capacitance | 460pF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 1465V dc |
| Standards/Approvals | IEC, CQC, CSA, UL, VDE |
| Pin Count | 2 |
| Termination Style | Radial |
| Lead Pitch | 10mm |
| Maximum AC Voltage | 1100V ac |
| Clamping Voltage VC | 2970V |
| Clamping Current | 100A |
| Maximum Surge Current | 6.5kA |
| Varistor Voltage | 820 V |
Key Features
- Constructed with a metal oxide material for enhanced durability.
- Rated clamping voltage is 2970 volts with a varistor voltage of 820 volts.
- Lead mount type with radial termination style and 2 pins for easy installation.
- Operating temperature range from -40°C to 105°C ensures reliable performance in harsh environments.
- Compact size with a 10mm diameter and dimensions suitable for varied industrial uses.
- Capacitance value of 460pF supports optimal filtering and transient suppression.
- Energy rating of 1 joule suitable for moderate surge energy absorption.
- Complies with IEC, CQC, CSA, UL and VDE standards for safety and quality assurance.
Product Description
TDK B72220S0511K101 Standard Metal Oxide Varistor is a high-performance electronic component designed for protecting circuits against voltage surges and transient spikes. Featuring a 460pF capacitance and a high clamping current of 100A, this varistor effectively safeguards sensitive electronics in industrial, commercial, and laboratory applications.
Constructed with durable metal oxide material and coated with flame-retardant material, the varistor ensures safe operation under demanding conditions. The component supports a maximum AC voltage of 1100V ac and maximum DC voltage of 1465V dc. Its compact design includes a 10mm diameter, 21.5mm length, and 7.1mm thickness, making it suitable for dense PCB assemblies.
The clamping voltage of 2970V and varistor voltage of 820V ensure precise energy absorption during voltage transients. The device operates reliably across a broad temperature range from -40°C to 105°C. This varistor includes a radial termination style with lead pitch of 10mm and 2 pins, facilitating straightforward through-hole mounting.
Meeting international safety standards including IEC, CQC, CSA, UL, and VDE, this varistor is an excellent choice for surge protection in diverse environments such as industrial equipment, power supplies, HVAC systems, and control panels. Its 1 joule energy rating allows it to absorb transient energy efficiently to prevent damage.
The leaded varistor elements with flame-retardant coating enhance safety and longevity of the component. Its reliable performance guarantees protection against electrical surges in varied electronic circuits.
Constructed with metal oxide material for increased surge protection. High clamping current rating of 100A for robust transient suppression. Capacitance of 460pF enables effective noise filtering. Wide operating temperature from -40°C to 105°C supports demanding applications.
Certified to IEC, CQC, CSA, UL, and VDE standards for quality assurance. Flame-retardant coating enhances insulation and safety. Compact radial leaded design with 2 pins and 10mm lead pitch for easy PCB mounting. Suitable for use in industrial, laboratory, commercial, and power equipment environments.
Energy rating of 1J for moderate energy absorption capabilities. Compatible with standard PCB layouts and offers reliable surge protection. Explore more TDK electronic components and Varistors for your surge protection requirements at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The clamping voltage of this model is 2970V.
It has a capacitance value of 460pF, which supports optimal filtering and transient suppression.
The maximum AC voltage is 1100V and the maximum DC voltage is 1465V.
This varistor operates reliably within a temperature range of -40°C to 105°C.
It features 2 pins for easy installation and mounting.
The energy rating is 1 joule, suitable for moderate surge energy absorption.
It has a diameter of 10mm, a length of 21.5mm, and a thickness of 7.1mm, making it compact for various applications.
It complies with IEC, CQC, CSA, UL, and VDE standards for safety and quality assurance.
The maximum surge current rating is 6.5kA.
This model utilizes a radial termination style with a lead pitch of 10mm.
The country of origin for this varistor is India.
It is constructed with a metal oxide material, enhancing its durability and performance.
