Bourns PV Varistor 120 pF 5A Surface Mount Clamping Voltage 455V Varistor Voltage 270V Tape & Reel PV175K3225R2

Bourns PV175K3225R2 is a high-quality surface mount varistor engineered for optimal surge protection in a wide range of electronic applications. With a capacitance of 120 pF and a clamping current rating of 5A, this varistor ensures reliable operation even under significant voltage surges. Its clamping voltage is 455V, providing robust suppression of transient events.

The PV series varistors are plastic-encapsulated to meet stringent non-flammability requirements (UL 94 V-0), offering durability and safety in demanding environments. This device is designed for surface mount use and available in tape & reel packaging, facilitating automatic pick-and-place assembly processes in modern electronics manufacturing.

Key attributes include a varistor voltage of 270V, maximum AC voltage support of 175V, maximum DC voltage of 225V, and maximum surge current of 400A. The energy rating is 9.5J, making it suitable for applications requiring robust electrical protection. The package dimensions are 8mm in length, 3.4mm in thickness and depth, with a 3225 case size. Operating temperature extends from -40°C up to 85°C.

The PV175K3225R2 is particularly noted for its reliable transient voltage suppression and is used in industrial, consumer, and automotive electronics for safeguarding sensitive components against voltage spikes. Its termination style is surface mount, and contacts are made of tinned copper sheet, ensuring both strong soldering and stable electrical connectivity.

The varistor is compliant with UL and RoHS standards for safety and environmental responsibility. Its compact footprint and SMD design enable versatile integration in circuit boards for power, signal, and connector protection across the electronics industry.

Applications cover industrial control systems, consumer electronics, telecommunications equipment, and automotive modules. This model is fabricated in Slovenia, ensuring high manufacturing standards and consistent quality.

120 pF varistor designed for surface mounting applications. Maximum clamping voltage of 455V provides reliable surge protection. Clamping current rated at 5A suitable for medium to high surge events. Varistor voltage is rated at 270V for broad electronic circuit compatibility.

Tape & reel packaging ensures ease of use in automated assembly processes. PV series with thermoplastic encapsulation meeting UL 94 V-0 non-flammable standard. Maximum AC voltage of 175V AC and DC voltage of 225V DC supported.

Energy rating of 9.5 Joules for robust protection performance. Operating temperature range from -40°C to 85°C enhances durability. Package size 3225 and contacts are tinned copper sheet for stable solder connections. Explore more surface mount surge protection solutions and Bourns Varistors in the Electronics Components category on EnvMart.
