ASSMANN WSW IC Socket Adapter Straight Through Hole Mount 2.54 mm Pitch 3A 100V ac AR 16-ST/T

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW IC Socket Adapter Straight Through Hole Mount 2.54 mm Pitch 3A 100V ac AR 16-ST/T

Name: ASSMANN WSW IC Socket Adapter Straight Through Hole Mount 2.54 mm Pitch 3A 100V ac AR 16-ST/T
Brand: ASSMANN WSW
SKU: 208597



Category IC Socket Adapter Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	100V ac
Brand	ASSMANN WSW
Orientation	Straight
Current	3A
Model	AR 16-ST/T
Mount Type	Through Hole
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Pitch	2.54mm
Contact Plating	Gold over Nickel
Connection Gender A	Male
Number of Contacts A	16
Connection A	DIP

Key Features

Supports 16 male contacts on both connection sides.
Designed with a through hole mounting type for stable PCB installation.
Contact plating consists of gold over nickel for reliable conductivity.
Can handle a current of 3A and a voltage rating of 100V AC.
Housing made from durable polybutylene terephthalate material.
Contact material is brass, ensuring robust electrical connections.
Package includes IC socket adapter suitable for electronic component interfacing.
Suitable for use in electronic manufacturing and prototyping applications.

Product Description

ASSMANN WSW AR 16-ST/T IC Socket Adapter is a high-quality electronic component designed for reliable interfacing of DIP integrated circuits. It features a straight orientation and a through hole mount type, enabling secure and effective PCB installation.

The adapter supports dual 16-pin male DIP connections with a 2.54 mm pitch, facilitating easy and precise IC socket adaptation. Contact surfaces are plated with gold over nickel to ensure low resistance and corrosion protection, while the contacts themselves are made from brass for durability and consistent conductivity.

The housing is manufactured from polybutylene terephthalate, a robust plastic material providing insulation and mechanical strength. Designed to operate safely up to 3 amps current and 100 volts AC voltage, this adapter meets the requirements for many electronic applications.

This product is ideal for industrial electronics manufacturing, laboratory prototyping, and field repair work where a reliable DIP to DIP socket interface is required. The through hole mount style guarantees strong mechanical insertion onto PCBs, suitable for both production and development environments.

The ASSMANN WSW AR 16-ST/T is made in China and supplied as a new component ready for installation without any additional standards approvals. This IC socket adapter improves workflow efficiency by enabling swift circuit modifications and component testing.

Supports 16 male contacts on both connections. Gold over nickel contact plating ensures excellent conductivity. Durable polybutylene terephthalate housing for insulation and strength. 3A current and 100V AC voltage rating for various electronic uses.

Straight orientation with through hole mount for secure PCB fitting. Brass contact material for reliable electrical contact quality. Suitable for industrial, laboratory, and manufacturing electronics applications. Enables easy DIP to DIP IC socket adaptation.
