ASSMANN WSW IC Socket Adapter Straight Through Hole Mount 2.54 mm Pitch DIP to DIP AR 28-ST/T
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 100V ac |
| Brand | ASSMANN WSW |
| Orientation | Straight |
| Current | 3A |
| Model | AR 28-ST/T |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Pitch | 2.54mm |
| Contact Plating | Gold over Nickel |
| Connection Gender A | Male |
| Number of Contacts A | 28 |
| Connection A | DIP |
Key Features
- Features 28 male contacts on both connection sides for reliable DIP interfacing.
- Contact plating is gold over nickel ensuring excellent conductivity and corrosion resistance.
- Supports current rating of 3A at 100V AC voltage.
- Constructed with brass contact material and polybutylene terephthalate housing for durability.
- Designed with a through hole mount and straight orientation for easy PCB integration.
- RoHS compliant and manufactured in China.
- Suitable for electronics applications requiring IC socket adaptation and secure electrical connections.
Product Description
ASSMANN WSW AR 28-ST/T is a high-quality IC socket adapter designed for straight through hole mounting with a pitch of 2.54 mm, facilitating DIP to DIP connections effectively. This adapter features 28 contacts on both the connection A and B sides, each male, meaning it is ideal for interfacing dual-inline package components with PCBs.
The contacts are plated with gold over nickel to ensure minimal electrical resistance and prevent corrosion over time, enhancing signal reliability.
It supports a current capacity of 3 amperes and operates safely up to 100 volts AC, making it suitable for various electronic circuit applications that require dependable electrical contacts.
The contact material is brass, combined with a polybutylene terephthalate housing, offering mechanical robustness and electrical insulation. The straight orientation and through hole mounting style simplify installation on printed circuit boards, making the adapter compatible with standard DIP layouts.
This component finds extensive use in electronics development, manufacturing, prototyping, and repair environments for adapting integrated circuits efficiently. Features 28 male contacts on both connection sides for reliable DIP interfacing.
Contact plating is gold over nickel ensuring excellent conductivity and corrosion resistance. Supports current rating of 3A at 100V AC voltage. Constructed with brass contact material and polybutylene terephthalate housing for durability.
Designed with a through hole mount and straight orientation for easy PCB integration. RoHS compliant and manufactured in China. Suitable for electronics applications requiring IC socket adaptation and secure electrical connections.
Explore more IC Socket Adapters and connectors in EnvMart’s Electronics & Electricals category to find components suited for your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 3A at 100V AC voltage.
The pitch of this model is 2.54 mm.
This adapter features 28 male contacts on both connection sides.
The contact material is brass, and the housing is made of polybutylene terephthalate.
It is designed for through hole mounting with a straight orientation.
Yes, it is RoHS compliant.
The adapter is manufactured in China.
It facilitates DIP to DIP connections, making it suitable for interfacing dual-inline package components with PCBs.
The contacts are plated with gold over nickel to ensure excellent conductivity and corrosion resistance.
It is suitable for electronics applications requiring IC socket adaptation and secure electrical connections.
The connection gender for both sides is male.
It can operate safely up to 100 volts AC.
