Winslow Straight Through Hole Mount 2.54 mm Pitch IC Socket Adapter SOP to DIP W9503-2RC
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Winslow |
| Orientation | Straight |
| Model | W9503-2RC |
| Mount Type | Through Hole |
| Housing Material | FR4 |
| Contact Material | Brass |
| Pitch | 2.54mm |
| Contact Plating | Tin over Nickel |
| Connection Gender A | Female |
| Number of Contacts A | 16 |
| Connection Gender B | Male |
| PCB | Epoxy Fibreglass FR4 |
| Connection A | SOP |
| Connection B | DIP |
Key Features
- Features a straight orientation for ease of mounting.
- Utilizes through hole mount type for secure PCB attachment.
- 16 female contacts on SOP side and 16 male contacts on DIP side.
- Contacts are brass material with tin over nickel plating for reliable conductivity.
- Housing is made of durable FR4 epoxy fiberglass PCB material.
- Supports SOIC to DIP socket conversion to facilitate compatibility between package styles.
- Maintains standard 2.54 mm pin pitch for DIP connection.
- Designed and manufactured in the United Kingdom ensuring quality standards.
Product Description
Winslow W9503-2RC is a straight through hole mount IC socket adapter designed for converting Small Outline Package (SOP) to Dual Inline Package (DIP) format with a standard 2.54 mm pitch. It is widely used in electronics development environments to facilitate board design flexibility by allowing SOIC device sockets to fit DIP footprints.
The adapter features 16 female contacts on the SOP side and 16 male contacts on the DIP side, with contacts manufactured from high-quality brass material plated with tin over nickel to ensure robust and consistent electrical connections. The housing material is FR4 epoxy fiberglass, a standard PCB material known for strength and electrical insulation properties.
This through hole mount adapter is engineered for straight orientation, which simplifies PCB assembly and integration in both prototyping and production phases. The adapter supports standard DIP pin spacing of 2.54 mm, making it compatible with a wide range of DIP sockets and boards.
Manufactured in the United Kingdom, the W9503-2RC emphasizes quality and reliability. This IC Socket Adapter reduces development costs by eliminating the need to redesign PCBs for different IC package styles and is useful in industrial, laboratory, and manufacturing applications where device package adaptation is necessary.
Adaptics technology converts SOIC packages to DIP footprints. Reliable brass contacts with tin over nickel plating ensure signal integrity. Robust FR4 housing supports environmentally stable mounting. Through hole design allows secure soldering onto PCB boards.
16 contacts for both SOP and DIP sides to maintain pin compatibility. Suitable for use in electronic component prototyping and design validation. Standard 2.54 mm pitch ensures broad compatibility with DIP sockets. Manufactured under stringent UK quality controls for durability and performance.
EnvMart provides extensive catalog support for electronic components and adapters like the Winslow W9503-2RC, enabling engineers and designers to source quality parts for their projects efficiently.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Winslow W9503-2RC has a standard pin pitch of 2.54 mm, ensuring compatibility with a wide range of DIP sockets.
This model features 16 female contacts on the SOP side and 16 male contacts on the DIP side.
The contacts are made of brass and are plated with tin over nickel, while the housing is constructed from FR4 epoxy fiberglass.
It utilizes a through hole mount type for secure attachment to PCB boards.
The adapter features a straight orientation, which simplifies the mounting process on PCBs.
The Winslow W9503-2RC is manufactured in the United Kingdom, ensuring adherence to quality standards.
It is designed to convert Small Outline Package (SOP) to Dual Inline Package (DIP) format, facilitating compatibility between different package styles.
This adapter is useful in industrial, laboratory, and manufacturing applications where device package adaptation is necessary.
The connection type on one side is SOP (female), and on the other side, it is DIP (male).
The tin over nickel plating on the brass contacts ensures reliable conductivity and signal integrity.
The FR4 epoxy fiberglass housing provides strength and electrical insulation properties, supporting stable mounting in various environments.
The product does not explicitly mention compliance with specific electrical standards; it is primarily designed for compatibility and functionality in electronic applications.
