Winslow IC Socket Adapter Straight Through Hole Mount 2.54 mm Pitch PLCC to PGA WA044127DSAJTRC
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Winslow |
| Orientation | Straight |
| Model | WA044127DSAJTRC |
| Mount Type | Through Hole |
| Housing Material | FR4 |
| Contact Material | Gold over Nickel |
| Pitch | 2.54mm |
| Contact Plating | Gold over Nickel |
| Connection Gender A | Female |
| Number of Contacts A | 44 |
| Connection Gender B | Male |
| Connection A | PLCC |
| Connection B | PGA |
Key Features
- This adapter features 44 female contacts on the PLCC side and 44 male contacts on the PGA side.
- The contact plating consists of gold over nickel for durability and efficient conductivity.
- Mount type is through hole with a straight orientation for reliable PCB installation.
- Housings are constructed from FR4 material, ensuring mechanical strength and electrical insulation.
- Produced in the United Kingdom, this product is designed for industrial electronic component applications.
- It has a 3.2 mm above board height to accommodate device mounting requirements.
- It supports the conversion between PLCC and PGA package styles, reducing the need for redesigning PCB layouts.
- No specific industry standards or approvals are assigned to this adapter.
Product Description
Winslow WA044127DSAJTRC IC Socket Adapter is a high-quality connector designed for electronic and electrical applications requiring PLCC to PGA package conversion with a 2.54 mm pitch. It features a through hole mount style with a straight orientation that ensures secure and stable installation on printed circuit boards (PCBs). This adapter supports 44 female contacts on the PLCC side and 44 male contacts on the PGA side, enabling seamless interconnection between different IC packages used in industrial electronics.
The contact plating of gold over nickel enhances corrosion resistance and electrical conductivity, guaranteeing reliable signal transmission and long service life under demanding operating conditions. The housing is made from FR4, a flame-resistant glass-reinforced epoxy laminate that provides excellent mechanical integrity and electrical insulation.
Manufactured in the United Kingdom, this adapter is suitable for use in various industrial sectors including electronics manufacturing, testing equipment, and PCB assembly environments. The adapter’s 3.2 mm profile height above the board allows accommodation of device packaging with precise mechanical tolerance.
This product facilitates cost-effective PCB design by allowing compatibility across PLCC and PGA packages without the need for board redesign or custom socket fabrication. It is ideal for prototyping, repair, and production line applications where package interchangeability is necessary.
This adapter has 44 female contacts on the PLCC side and 44 male contacts on the PGA side. Contact plating is gold over nickel for superior conductivity and durability. Mount type is through hole with a straight orientation for secure PCB attachment.
Housing material is FR4 offering mechanical stability and insulation. The pitch of contacts is 2.54 mm, standard for multiple IC applications. It is manufactured in the United Kingdom ensuring quality standards. Applicable for multiple industrial and electronics testing use cases.
Explore EnvMart for more Winslow electronic components and IC Socket Adapters to meet your industrial and assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contacts on this IC socket adapter have a pitch of 2.54 mm, which is standard for multiple IC applications.
The PLCC side of the adapter features 44 female contacts, allowing for secure connections with compatible IC packages.
This model utilizes a through hole mount type, which ensures stable and secure installation on printed circuit boards (PCBs).
The housing of the adapter is made from FR4 material, while the contact plating consists of gold over nickel for enhanced conductivity and durability.
The orientation of this adapter is straight, facilitating easy installation on PCBs.
This adapter supports connections between PLCC (female) and PGA (male) package styles, enabling seamless interconnection between different IC packages.
The adapter has a height of 3.2 mm above the board, accommodating device mounting requirements.
This product is manufactured in the United Kingdom, ensuring adherence to quality standards.
This adapter is suitable for various industrial applications including electronics manufacturing, testing equipment, and PCB assembly environments.
The gold over nickel contact plating enhances corrosion resistance and electrical conductivity, ensuring reliable signal transmission.
The PGA side of the adapter features 44 male contacts, allowing for compatibility with corresponding IC packages.
The model number of this socket adapter is WA044127DSAJTRC, which identifies its specific configuration and features.
