ASSMANN WSW 2.54 mm Pitch Vertical 18 Way Through Hole Turned Pin Open Frame DIL Socket 3A AR 18 HZL-TT

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW 2.54 mm Pitch Vertical 18 Way Through Hole Turned Pin Open Frame DIL Socket 3A AR 18 HZL-TT

Name: ASSMANN WSW 2.54 mm Pitch Vertical 18 Way Through Hole Turned Pin Open Frame DIL Socket 3A AR 18 HZL-TT
Brand: ASSMANN WSW
SKU: 208524
Price: 0.57 USD
Availability: InStock



Category DIL Socket Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	100V ac
Brand	ASSMANN WSW
Orientation	Vertical
Current	3A
Frame Type	Open Frame
Length	22.86mm
Model	AR 18 HZL-TT
Depth	3mm
Width	10.16mm
Mount Type	Through Hole
Housing Material	Polybutylene Terephthalate
Contact Material	Brass, Phosphor Bronze
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	18
Pin Type	Turned
Row Width	7.62mm

Key Features

Features a vertical orientation with an open frame design for effective cooling.
Constructed with brass and phosphor bronze contacts providing reliable conductivity.
Contacts are tin plated and pins are turned for precision soldering.
Mount type is through hole suitable for PCB mounting.
Rated for 3A current and 100V AC voltage operation.
Operating temperature range from -40°C to 105°C ensures durability in various environments.
Compact dimensions with a length of 22.86 mm, width of 10.16 mm, depth of 3 mm, and row width of 7.62 mm.
Housing made from flame retardant Polybutylene Terephthalate (PBT) material.

Product Description

ASSMANN WSW AR 18 HZL-TT is a high-quality 18 way through hole DIL socket featuring a 2.54 mm pitch and designed with a vertical orientation and open frame structure.

This socket is engineered for industrial and electronic applications requiring reliable IC connection and excellent thermal management due to its open frame design. The turned pin contacts are precision-made from brass and phosphor bronze, plated with tin for optimal solderability and electrical conductivity.

The socket operates safely at 3 amperes current and supports up to 100V AC, making it widely suitable for integration in electronic circuits on printed circuit boards requiring through hole mounting.

The robust housing is molded from Polybutylene Terephthalate, a flame retardant thermoplastic providing durability and compliance with UL94V-0 standards. Its compact dimensions allow easy placement in tight spaces while ensuring secure contact.

With an operating temperature range from -40°C to 105°C, this socket is engineered to withstand demanding thermal environments commonly found in industrial electronics, manufacturing equipment, and laboratory instrumentation.

Vertical, open frame socket with 2.54 mm pitch and 18 contacts. Turned pin contact type with tin plating for durability. Through hole mounting facilitates stable PCB installation. Rated for 3A current and 100V AC voltage operation.

Compact size: 22.86 mm length, 10.16 mm width, 3 mm depth. Housing made of flame retardant Polybutylene Terephthalate (PBT). Operating temperature from -40°C to 105°C.

This DIL socket is ideal for use in electronics manufacturing, industrial control systems, automotive electronics, and other commercial and industrial applications requiring dependable connector performance.

Explore more industrial-grade DIL Sockets and components in EnvMart’s comprehensive Electronics & Electricals category for optimal sourcing and enhanced production reliability.
