ASSMANN WSW 10-Way IDC Connector Male for Cable, 2 Row AWLP 10/3,2-T

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW 10-Way IDC Connector Male for Cable, 2 Row AWLP 10/3,2-T

Name: ASSMANN WSW 10-Way IDC Connector Male for Cable, 2 Row AWLP 10/3,2-T
Brand: ASSMANN WSW
SKU: 208332
Price: 0.76 USD
Availability: InStock



Category IDC Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Brand	ASSMANN WSW
Orientation	Straight
Current	3A
Model	AWLP 10/3,2-T
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	AWLP
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Tin, Nickel
Number of Contacts	10
Contact Gender	Male
Connector Gender	Male
Shrouded/Unshrouded	Unshrouded

Key Features

Features 10 contacts arranged in 2 rows for precise connections.
Unshrouded design with straight male connectors ensures easy cable mounting.
Operates safely at 250V AC voltage and withstands temperatures from -40°C to 105°C.
Constructed with brass contact material and polybutylene terephthalate housing for durability.
Contacts plated with tin and nickel for corrosion resistance.
Solder termination type for secure electrical connections.
Designed without specific approval standards but manufactured to high-quality series AWLP.
Connector suitable for industrial electronic applications requiring robust IDC connections.

Product Description

ASSMANN WSW AWLP 10/3,2-T is a 10-way IDC Connector Male designed for cable connections, featuring a two-row configuration and a pitch of 2.54mm. This connector is ideal for electronics components requiring reliable and efficient interfacing with cables in industrial and manufacturing environments.

The connector provides 10 high-quality brass contacts with tin and nickel plating, offering excellent conductivity and corrosion resistance. Its robust polybutylene terephthalate housing ensures mechanical stability and durability under varying operational conditions.

Rated for 3A of current and 250V AC of voltage, the AWLP 10/3,2-T supports secure and safe electrical performance in demanding applications. It is engineered to operate effectively within the temperature range of -40°C up to 105°C, making it suitable for both harsh and standard environments.

The male connector with straight orientation and unshrouded design allows for straightforward cable mounting and solder termination, facilitating ease of installation on circuit boards.

This connector set complies with the AWLP series design principles, representing a trusted product line for IDC transition connectors at 2.54mm pitch. Manufactured in China, it aligns with quality assurance benchmarks expected in modern industrial electronic connectors.

Features 10 contacts arranged in 2 rows for precise connections. Unshrouded design enables ease of cable mounting and solder termination. Supports 250V AC operation and 3A current capacity. Operates in temperatures ranging from -40°C to 105°C safely.

Constructed with brass contacts and polybutylene terephthalate housing for durability. Contact plating of tin and nickel enhances corrosion resistance. Suitable for electronics and industrial cable connection applications.
