Molex 18-Way IDC Connector Male for Through Hole, 1 Row 250V ac 1.2A Pitch 1.27mm 90325-0018

Molex 90325-0018 is an 18-Way IDC Connector, male, designed for through-hole mounting with one row of pins. It operates at 250V ac and handles currents up to 1.2A, making it suitable for various electronics and industrial applications requiring compact and reliable wire-to-board connections.

This IDC connector features a fine 1.27mm pitch which allows for high-density PCB layouts, optimizing space and functionality. The connector is unshrouded, with brass contacts plated with tin over nickel, ensuring excellent conductivity and corrosion resistance. The housing is crafted from durable polybutylene terephthalate, providing excellent insulation and mechanical strength for demanding environments.

The through-hole mounting type offers firm mechanical attachment to circuit boards through robust solder tails, enhancing assembly reliability. The operating temperature range is from -40°C to 105°C, making it durable in extreme conditions typical in automotive, industrial, and consumer electronics sectors.

This product is part of the Picoflex series that offers low-profile, space-efficient connectors with excellent polarisation and integral strain relief. It is ideal for automotive and consumer electronics industries where vibration and shock resistance is required. The connector complies with relevant UL and CSA approvals, enhancing safety and compliance assurance.

The connector is manufactured in Ireland under strict quality controls, ensuring high performance and reliability. The package is ready for insertion into machinery, improving production efficiency in manufacturing environments.

Key features include 18 contacts in one row, friction lock and polarization, and compatibility with Picoflex 90327 series housings. This IDC connector supports applications in industrial, automotive, telecommunications, and consumer electronic devices requiring robust electrical connections in tight spaces.

This connector supports 1.2A current and 250V ac voltage ratings. The pitch of 1.27mm allows for dense pin placement. Made with brass contacts plated with tin over nickel for enhanced conductivity. Polybutylene terephthalate housing provides durability and insulation.

Through-hole mount with rigid solder tails ensures firm PCB connection. Operating temperature range supports harsh environments. Low-profile Picoflex series design for compact applications. Ideal for automotive, manufacturing, consumer electronics, and other industrial uses.

Manufactured with high quality standards in Ireland. Explore additional Molex IDC Connectors and related electronic components in EnvMart's catalog for optimized electronic system designs.
