Molex KK 254 Series Right Angle Through Hole PCB Socket, 3-Contact, 1 Row, 2.54 mm Pitch, 2.5A, 250V 22-15-2036
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 2.5A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | KK 254 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Female |
| Connector System | Board-to-Board, Signal |
Key Features
- Operates at a current rating of 2.5A and voltage rating of 250V.
- Features a nylon housing material with UL94 V-0 flammability rating.
- Designed for through hole mount type with board-to-board, signal connector system.
- Contact materials include brass contacts with tin plating for reliable conductivity.
- Operating temperature ranges from -40°C to 105°C, suitable for demanding environments.
- Connector orientation is right angle to optimize PCB layout space.
- Female contact gender designed for socket use in KK 254 series board connectors.
- Made in Mexico, meeting UL (E29179) and CSA (LR 19980) approvals for quality assurance.
Product Description
Molex 22-15-2036 KK 254 Series Right Angle Through Hole PCB Socket is a specialized electronic component featuring 3 contacts arranged in 1 row with a 2.54 mm pitch. This PCB socket is designed for solder termination and employs a right angle orientation to assist in efficient PCB layout and assembly.
The device supports a current rating of 2.5A and a voltage rating of 250V, making it suitable for a variety of electronic and electrical applications where reliable connections are required. The housing is made from UL94 V-0 rated nylon, providing flame retardance and mechanical durability.
Mounting is through hole, facilitating secure attachment to printed circuit boards, while the connector system supports board-to-board and signal connections. The brass contacts with tin plating ensure excellent electrical conductivity and corrosion resistance. The socket operates reliably within a temperature range from -40°C to 105°C, allowing it to perform in diverse industrial, manufacturing, and electronic laboratory environments.
These sockets are compliant with UL (E29179) and CSA (LR 19980) standards, confirming quality and safety compliance for use in sensitive and mission-critical electronic equipment. Operates at a current rating of 2.5A and voltage rating of 250V.
Features a nylon housing material with UL94 V-0 rating for flame retardancy. Right angle orientation for optimized PCB space utilization. Brass contacts with tin plating ensure reliable electrical performance. Suitable for industrial, electronic, laboratory, and manufacturing use cases.
Mount Type: Through Hole for secure PCB mounting. 3 contacts arranged in 1 row with 2.54 mm pitch spacing. Operating temperature range of -40°C to 105°C.
This Molex KK 254 Series PCB Socket is ideal for electronics manufacturers and engineers requiring dependable, quality connectors for signal and board-to-board interfacing. Browse more Molex components and PCB socket solutions on EnvMart for comprehensive industrial and electronic applications.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket operates at a current rating of 2.5A and a voltage rating of 250V.
It features a 2.54 mm pitch and has 3 contacts arranged in 1 row.
This model utilizes solder termination for secure connections.
The connector is designed with a right angle orientation to optimize PCB layout space.
The housing is made from nylon, while the contacts are brass with tin plating for reliable conductivity.
It operates reliably within a temperature range from -40°C to 105°C.
This model is manufactured in Mexico.
The connector system supports board-to-board and signal connections.
This PCB socket has 1 row of contacts.
It meets UL (E29179) and CSA (LR 19980) standards for quality assurance.
The contact gender is female, designed for socket use in the KK 254 series connectors.
The maximum operating temperature for this model is 105°C.
