Molex 26-Way IDC Connector Male for Surface Mount, 1 Row, 1.2A Current, 250V AC Voltage 90814-0926

Molex 90814-0926 is a 26-way IDC male connector designed for surface mounting, featuring a single row configuration and a 1.27 mm pitch suitable for PCB applications. This connector supports a continuous current of 1.2 amps and a voltage rating of 250 volts AC, making it well-suited for various industrial and consumer electronic devices.

The connector's construction includes brass contacts plated with tin over nickel, housed in durable nylon material to provide robustness and longevity. Its unshrouded design incorporates friction locks and polarization features to ensure secure and accurate mating, minimizing connection errors.

Operating reliably over a temperature range from -40°C to 105°C, this connector maintains performance in challenging environments, including automotive and industrial conditions subject to vibration and shock. The IDC termination supports rapid assembly and reduces installation time.

The 90814-0926 is part of the Picoflex series, which offers significant space savings of approximately 50% compared to traditional pitches, with a low profile mated height of only 6.4 mm. These features make it optimal for high-density circuit boards where space and reliability are critical.

The connector is compatible with Picoflex PF-50 series cable assemblies, which are pre-terminated and ideally suited for automotive and consumer electronics manufacturing where quality and throughput are paramount.

Features a 1.27 mm pitch Picoflex header for high-density PCB designs. Includes friction lock and polarisation for secure connections. Brass contacts with tin over nickel plating and nylon housing. Temperature rating from -40°C to 105°C for rugged application environments.

Supports IDC termination type with surface mount and straight orientation. Designed for reliable automotive and manufacturing electronics use. Low profile design saves space and improves design flexibility. High resistance to vibration and shock ensures long-term reliability.

This Molex IDC connector is suitable for use in industrial electronics, automotive applications, consumer electronics, manufacturing lines, and other environments requiring compact, durable, and reliable wire-to-board connections. It supports designs where space saving, mechanical robustness, and electrical performance are critical.
