Texas Instruments CMOS Inverter Schmitt Trigger Input 6-Element 14-Pin SOIC SN74AC14DR

Name: Texas Instruments CMOS Inverter Schmitt Trigger Input 6-Element 14-Pin SOIC SN74AC14DR
Brand: Texas Instruments
SKU: 203398
Price: 0.52 USD
Availability: InStock



Category Inverters ICs Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	1.58mm
Length	8.65mm
Model	SN74AC14DR
Width	3.91mm
Mount Type	Surface
Compatibility	Input CMOS, Output CMOS
Series	SN74AC14
Input Type	Schmitt Trigger
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Operating Voltage	1.5 to 5.5 V and 2 to 6 V
Pin Count	14
Number of Elements per Chip	6
Maximum Supply Voltage	6V
Logic Family	AC
Logic Function	Inverter
Minimum Supply Voltage	2V
Maximum High Level Output Current	-24mA
Maximum Propagation Delay Time @ CL	15ns
Maximum Low Level Output Current	24mA

Key Features

Contains 6 inverter elements with Schmitt Trigger input for signal conditioning.
Packaged in a 14-pin Small Outline Integrated Circuit (SOIC) for surface mounting.
Operates across a voltage range of 1.5 to 5.5 volts and 2 to 6 volts compatibility.
Maximum propagation delay time at capacitive load is 15 nanoseconds for fast switching.
Supports operating temperatures from -40°C to +85°C suitable for various environments.
Maximum high level output current is -24 milliamps and maximum low level output current is 24 milliamps.
Mount type is surface-mount technology (SMT) for efficient PCB assembly.

Product Description

Texas Instruments SN74AC14DR is a high-performance CMOS inverter integrated circuit with a Schmitt Trigger input designed for logic signal conditioning and waveform shaping in industrial and electronic applications.

This IC contains 6 independent inverter elements in a 14-pin SOIC package, providing high-speed switching with a maximum propagation delay time of 15 nanoseconds at specified load conditions. It operates reliably over a wide voltage range from 1.5 to 5.5 volts and 2 to 6 volts, accommodating diverse power supply environments.

The robust design supports a broad operating temperature range from -40°C to +85°C, ensuring stable performance in industrial, manufacturing, and laboratory electronics environments. Its maximum high and low-level output currents of -24 mA and 24 mA respectively enable driving diverse loads.

Compact dimensions (8.65 mm length, 3.91 mm width, and 1.58 mm height) coupled with surface-mount package type allow for efficient PCB integration in modern electronic assemblies. Key use cases include signal conditioning, waveform shaping, and digital logic interfacing in industrial automation, laboratory equipment, and power supply modules.

Contains 6 inverter elements with Schmitt Trigger inputs for precise electronic control. 14-pin SOIC package compatible with surface mount technology for compact circuit designs. Wide operating voltage range and temperature tolerance ensure versatility.

Fast switching with 15 ns maximum propagation delay enhances signal response. Suitable for industrial, laboratory, and manufacturing electronic applications. Explore more semiconductor and logic IC solutions at EnvMart for your industrial and laboratory automation needs.
