onsemi 1.20 V Zener Diode Surface Mount 500 mW 5% Tolerance 2-Pin SOD-123 MMSZ5250BT1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi 1.20 V Zener Diode Surface Mount 500 mW 5% Tolerance 2-Pin SOD-123 MMSZ5250BT1G

Name: onsemi 1.20 V Zener Diode Surface Mount 500 mW 5% Tolerance 2-Pin SOD-123 MMSZ5250BT1G
Brand: onsemi
SKU: 196988
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.35mm
Length	3.86mm
Model	MMSZ5250BT1G
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOD-123
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	6.2mA
Maximum Reverse Leakage Current	100nA
Nominal Zener Voltage Vz	20V
Zener Type	Voltage Regulator
Maximum Zener Impedance	25Ω
Surface Mount case	SOD-123

Key Features

Offers a nominal zener voltage of 20 V with voltage regulator type functionality.
Capable of dissipating a maximum power of 500 mW ensuring reliability in surface-mount applications.
Features a 2-pin SOD-123 package suitable for automated PCB assembly.
Operates within a temperature range of -55°C to 150°C for versatile industrial use.
Test current of 6.2 mA and maximum zener impedance of 25 ohms providing stable operation.
Maximum reverse leakage current is minimal at 100 nA enhancing efficiency.
Constructed as a single diode element providing targeted discrete semiconductor functions.

Product Description

onsemi MMSZ5250BT1G is a 1.20 V nominal Zener Diode specially engineered for voltage regulation in electronic circuits, housed in a surface mount 2-pin SOD-123 package. Rated for a maximum power dissipation of 500 mW, it is ideal for compact and automated PCB assembly in industrial electronics manufacturing.

This diode features a voltage tolerance of ±5%, a test current of 6.2 mA, and a maximum zener impedance of 25 ohms, ensuring precision voltage control and minimal signal distortion. Its low maximum reverse leakage current of 100 nA contributes to higher overall circuit efficiency and reliability.

Designed to operate efficiently over a comprehensive temperature range from -55°C to 150°C, this component is suitable for diverse applications across industrial, electronics manufacturing, telecommunications, instrumentation, and automotive electronics sectors that do not require automotive certifications.

The single diode element configuration maximizes performance for discrete semiconductor needs in voltage regulation, making it ideal for power management and protective circuit designs. Its surface mount form factor facilitates automated assembly lines, improving production efficiency.

Nominal zener voltage of 20 V with ±5% tolerance. Surface-mount 2-pin SOD-123 package for compact design. Maximum power dissipation of 500 mW suitable for low power applications. Operation across -55°C to 150°C temperature range.

Test current of 6.2 mA and low zener impedance of 25 ohms. Maximum reverse leakage current limited to 100 nA. Compliant with RoHS standards ensuring environmental safety.

This onsemi MMSZ5250BT1G Zener Diode integrates reliability and efficiency needed for electronic component design in industrial, manufacturing, and testing environments. Explore more semiconductor and zener diode solutions in the Electronics & Electricals category at EnvMart.
