onsemi 1-Element Bi-Directional TVS Diode 600 W 2-Pin DO-15 P6KE47CA
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 3.6mm |
| Brand | onsemi |
| Height | 3.56mm |
| Length | 7.62mm |
| Model | P6KE47CA |
| Width | 3.56mm |
| Mount Type | Through Hole |
| Series | P6KE |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-15 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 64.8V |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 44.7V |
| Maximum Reverse Stand-off Voltage Vwm | 40.2V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 9.3A |
| Maximum Reverse Leakage Current | 5μA |
Key Features
- Single diode configuration for effective transient voltage suppression.
- Bi-directional direction type ensures protection in both polarity directions.
- Minimum breakdown voltage of 44.7 V for reliable operation.
- Through hole mount type with DO-15 package for easy PCB assembly.
- Maximum peak pulse current of 9.3 A supports high surge current handling.
- Operating temperature range from -65°C to 175°C for robust performance.
- Clamping voltage of 64.8 V protects sensitive circuits from voltage spikes.
- Maximum reverse leakage current of 5 μA minimizes power loss.
Product Description
The onsemi P6KE47CA is a 1-element bi-directional transient voltage suppression (TVS) diode designed to protect sensitive electronic components against voltage spikes and surges. With a peak pulse power dissipation rating of 600 watts, this diode effectively clamps high transient voltages to prevent damage in various industrial and commercial electronic circuits.
Featuring a single diode configuration and a bi-directional direction type, the P6KE47CA provides robust protection from transient voltages in both polarity directions. It supports a minimum breakdown voltage of 44.7 volts and a maximum reverse stand-off voltage of 40.2 volts, making it suitable for a wide range of voltage protection needs.
The diode is housed in a durable DO-15 through-hole package, with compact dimensions measuring 7.62 mm in length, 3.56 mm in width and height, and 3.6 mm in diameter. It is rated for a maximum peak pulse current of 9.3 A and offers a low maximum reverse leakage current of 5 microamperes, minimizing power loss during normal operation.
Operating reliably across a wide temperature range from -65°C to 175°C, this component is designed to withstand harsh environmental conditions encountered in industrial, electronics manufacturing, power supply modules, and automotive support equipment. The clamping voltage of 64.8 V ensures effective suppression of transient voltage spikes, thereby protecting critical circuits.
Single diode configuration for transient voltage suppression. Bi-directional operation for polarity protection. Through hole mounting in DO-15 package. Wide operating temperature range from -65°C to 175°C. Compact axial package dimensions for easy PCB integration.
High surge current handling capability up to 9.3 A. 600 W peak pulse power dissipation. Low reverse leakage current enhances efficiency. Clamp voltage of 64.8 V safeguards circuits. Ideal for power and electronic component protection.
Use this diode in power supplies, industrial machinery, automotive electronics, and telecommunications systems to enhance transient voltage resilience and improve system longevity. For additional design assistance, 3D models, footprints, and schematics are available. Browse more semiconductor and TVS Diode products on EnvMart for industrial-grade electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The P6KE47CA has a peak pulse power dissipation rating of 600 watts, allowing it to effectively clamp high transient voltages.
The minimum breakdown voltage for the P6KE47CA is 44.7 volts, ensuring reliable operation during voltage spikes.
The clamping voltage of this model is 64.8 volts, which protects sensitive circuits from voltage spikes.
The maximum reverse leakage current for the P6KE47CA is 5 microamperes, which helps minimize power loss during normal operation.
This diode has dimensions of 7.62 mm in length, 3.56 mm in width, and a diameter of 3.6 mm, making it compact for PCB integration.
The P6KE47CA operates reliably across a temperature range from -65°C to 175°C, suitable for harsh environments.
This model is housed in a DO-15 through-hole package, facilitating easy assembly on PCBs.
The maximum peak pulse current for the P6KE47CA is 9.3 A, allowing it to handle high surge currents effectively.
The P6KE47CA features a single diode configuration, providing bi-directional protection against voltage transients.
This diode is bi-directional, ensuring protection against voltage spikes in both polarity directions.
This TVS diode is suitable for use in power supplies, industrial machinery, automotive electronics, and telecommunications systems.
The maximum reverse stand-off voltage for the P6KE47CA is 40.2 volts, making it suitable for various voltage protection needs.
