Wurth Elektronik WR-PHD Series Straight Surface PCB Socket 8-Contact Dual Row 2 mm Pitch Solder 200V 2A 62100821821

Name: Wurth Elektronik WR-PHD Series Straight Surface PCB Socket 8-Contact Dual Row 2 mm Pitch Solder 200V 2A 62100821821
Brand: Wurth Elektronik
SKU: 190379
Price: 1.77 USD
Availability: InStock



Category PCB Sockets Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	200V
Brand	Wurth Elektronik
Orientation	Straight
Current	2A
Mount Type	Surface
Housing Material	Polyamide
Contact Material	Copper Alloy
Series	WR-PHD
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2mm
Standards/Approvals	DIN ISO 2768, DIN EN 61760-2, UL Approval E323964, RoHS Approval, REACh Approval Conform or declared
Contact Plating	Gold
Number of Contacts	8
Contact Gender	Female
Connector System	Board-to-Board

Key Features

The socket supports a current rating of 2A and voltage rating of 200V for reliable electrical performance.
Constructed with polyamide housing material to ensure durability and heat resistance.
Features gold-plated copper alloy contacts to provide low contact resistance and corrosion resistance.
Designed for surface mounting on PCBs with a straight orientation and solder termination type.
Rated to operate in temperatures ranging from -40°C to 105°C for versatile industrial applications.
Complies with international standards including DIN ISO 2768, DIN EN 61760-2, and has UL Approval E323964.
Meets RoHS and REACh compliance ensuring environmental safety and sustainability.
Designed for up to 500 mating cycles to support repeated connections during product lifecycle.

Product Description

Wurth Elektronik 62100821821 WR-PHD Series Straight Surface PCB Socket is a robust 8-contact connector designed for board-to-board applications requiring reliable electrical and mechanical performance. Featuring a 2-row configuration with a 2 mm pitch, this socket supports current up to 2A and voltage up to 200V, making it suitable for various electronic equipment designs.

The connector body is made of high-quality polyamide housing, providing excellent durability and resistance to operational stresses. Copper alloy contacts are gold-plated to ensure superior conductivity and resistance against corrosion and wear, contributing to a low contact resistance of approximately 20 mΩ.

Built for surface mount technology (SMT), the socket uses solder termination and is oriented straight for easy PCB assembly. It is rated for a wide operating temperature range from -40°C to +105°C, fitting industrial, commercial, and electronic manufacturing environments.

Certified to rigorous standards including DIN ISO 2768, DIN EN 61760-2, and UL E323964, it guarantees compliance with quality and safety benchmarks. Furthermore, this component is RoHS and REACh compliant, reflecting adherence to current environmental directives.

The socket is designed to withstand up to 500 mating cycles, suitable for applications requiring repeated connector insertion and removal over its lifespan. Manufactured in China, this WR-PHD series socket is an excellent choice for engineers seeking reliable, high-performance PCB connectors.

The socket supports a current rating of 2A and voltage rating of 200V for reliable electrical performance. Constructed with polyamide housing material to ensure durability and heat resistance. Features gold-plated copper alloy contacts to provide low contact resistance and corrosion resistance.

Designed for surface mounting on PCBs with a straight orientation and solder termination type. Rated to operate in temperatures ranging from -40°C to 105°C for versatile industrial applications. Complies with international standards including DIN ISO 2768, DIN EN 61760-2, and has UL Approval E323964.

Meets RoHS and REACh compliance ensuring environmental safety and sustainability. Designed for up to 500 mating cycles to support repeated connections during product lifecycle. Explore more Wurth Elektronik PCB Sockets and connectors at EnvMart to fulfill your industrial and electronic component needs.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This PCB socket supports a voltage rating of 200V and a current rating of 2A, ensuring reliable electrical performance.

It is rated to operate in temperatures ranging from -40°C to 105°C, making it suitable for various industrial applications.

The housing material is polyamide, while the contacts are made of copper alloy with gold plating to ensure low contact resistance and corrosion resistance.

This connector features 8 contacts arranged in a 2-row configuration with a 2 mm pitch.

It uses solder termination, which is typical for surface-mounted technology applications.

This model complies with DIN ISO 2768, DIN EN 61760-2, and has UL Approval E323964, along with RoHS and REACh compliance.

The socket is designed for straight orientation, facilitating easy assembly on PCBs.

It is designed to withstand up to 500 mating cycles, suitable for applications requiring repeated connections.

The contact gender of this socket is female, making it compatible with male connectors in board-to-board applications.

This socket is suitable for various electronic equipment designs, particularly in industrial and commercial environments.

The specific weight and dimensions of this socket are not provided in the available data.
