STMicroelectronics 100 V 40 A Schottky Diode Surface Mount TO-263 Package STPS41H100CG
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 4.6mm |
| Length | 10.4mm |
| Model | STPS41H100CG |
| Width | 9.35mm |
| Mount Type | Surface |
| Series | STPS41H100C |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-263 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 40A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 10μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 220A |
| Maximum Forward Voltage Vf | 0.62V |
| - Capacitance | 45 pF |
Key Features
- Designed for high frequency switch mode power supplies.
- Features negligible switching losses and avalanche rated capability.
- Offers low leakage current and good trade-off between leakage and forward voltage drop.
- Insulated ISOTOP package provides 2500 VRMS insulation and 45 pF capacitance.
- Operates reliably up to 175°C maximum temperature.
- Common cathode diode configuration with a 3-pin layout.
- Peak Non-Repetitive Forward Surge Current is 220 A for transient conditions.
- Suitable for secondary rectification in various industrial and electronic power applications.
Product Description
STMicroelectronics STPS41H100CG Schottky Diode is a robust power semiconductor device designed for use in high frequency switch mode power supplies. It is surface-mounted in a TO-263 (D2PAK) insulated package to ensure efficient thermal management and electrical isolation with an insulation rating of 2500 VRMS and low capacitance of 45 pF.
This 3-pin diode features a common cathode configuration and supports a maximum continuous forward current rating of 40 A along with a peak reverse repetitive voltage of 100 V. The device tolerates a peak non-repetitive forward surge current of 220 A, making it reliable for transient conditions encountered in power electronics.
The diode delivers a maximum forward voltage drop of 0.62 V for efficient conduction, while its avalanche rating and low leakage current enhance durability and operational efficiency. It can operate across a broad temperature range from -65°C to 175°C, suitable for demanding industrial environments.
Its compact size of 10.4 mm length, 9.35 mm width, and 4.6 mm height facilitates usage in space-constrained electronic assemblies. STPS41H100CG is ideal for secondary rectification tasks in power supplies, inverter circuits, and other industrial systems requiring efficient and reliable Schottky rectifiers.
Designed for high frequency switch mode power supplies. Features negligible switching losses and avalanche rated capability. Offers low leakage current and balanced forward voltage drop. Insulated TO-263 (ISOTOP) package enabling electrical isolation.
Operates within -65°C to 175°C temperature range. Peak non-repetitive forward surge current of 220 A. Compact dimensions support dense assembly layouts. Supports maximum continuous forward current of 40 A at 100 V.
This STMicroelectronics Schottky diode is widely applicable in industrial, manufacturing, electronic component design, HVAC systems, and power treatment applications. For more semiconductor diodes and high-performance components, explore EnvMart's Semiconductors category.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of the STMicroelectronics STPS41H100CG Schottky diode is 40 A.
This model has a peak reverse repetitive voltage rating of 100 V.
The dimensions of the STPS41H100CG diode are 10.4 mm in length, 9.35 mm in width, and 4.6 mm in height.
The peak non-repetitive forward surge current rating for this diode is 220 A.
The operating temperature range for the STPS41H100CG is from -65°C to 175°C.
This diode is packaged in a TO-263 (D2PAK) surface mount package.
The maximum forward voltage drop of the STPS41H100CG is 0.62 V.
The STPS41H100CG features a common cathode diode configuration.
The capacitance of the STPS41H100CG is 45 pF.
Yes, the STPS41H100CG is designed for high frequency switch mode power supplies, featuring negligible switching losses.
The peak reverse current for the STPS41H100CG is 10 μA.
The STPS41H100CG is manufactured in India.
