Nexperia 100 V 215 mA General Purpose Diode Surface Mount SOT-23 Package BAV70,215

Nexperia BAV70,215 is a general purpose switching diode designed for low leakage and high voltage electronic circuit applications. Featuring a peak reverse repetitive voltage of 100 V and a maximum continuous forward current of 215 mA, this diode operates reliably within a temperature range of -65°C to 150°C, making it suitable for demanding industrial, automotive, and telecommunications uses.

Encased in a compact 3-pin SOT-23 surface mount package with dimensions 3 mm (length) × 1.4 mm (width) × 1 mm (height), it supports high-density circuit designs where space saving is critical. The common cathode configuration facilitates a wide range of general purpose rectifier applications.

With a low maximum forward voltage of 1.25 V, the diode ensures efficient conduction while minimizing power dissipation. Its peak non-repetitive forward surge current of 4 A allows handling occasional transient overloads.

The diode exhibits a very fast peak reverse recovery time of 4 ns, suitable for high frequency switching in power management and signal conditioning circuits. The ultra-low peak reverse current of 500 nA minimizes leakage current and enhances overall circuit efficiency.

Meeting the stringent automotive standard AEC-Q101, the BAV70,215 diode provides robust performance required in automotive electronics and harsh environments. The product is manufactured in China and supplied in packaging optimized for automated assembly lines.

Supports low-leakage and high-voltage circuit designs with high switching speed. Low forward voltage drop of 1.25 V for efficient conduction. Common cathode configuration suitable for general-purpose rectification. Compact dimensions of 3 mm length, 1.4 mm width, and 1 mm height for high-density PCB layouts.

Wide operating temperature range from -65°C to 150°C for reliable industrial performance. Peak non-repetitive forward surge current capability up to 4 A. Meets automotive standard AEC-Q101 ensuring quality and reliability.

Peak reverse recovery time of 4 ns supporting high frequency switching applications. Ultra-low peak reverse current of 500 nA reduces leakage losses.

This diode is ideal for use in industrial electronic devices, automotive electronics, telecommunications equipment, and power supply circuits. It supports applications requiring compact size, high reliability, and fast switching characteristics.
