Wurth Elektronik 1317 Series PCB Terminal Block, 5-Contact, 5 mm Pitch, Through Hole Mount, Horizontal 691131710005

Wurth Elektronik 691131710005 PCB Terminal Block belongs to the 1317 series featuring 5 contacts and a 5 mm pitch designed for secure through-hole mounting on printed circuit boards. This terminal block has a horizontal wire entry and ensures reliable connectivity with a current rating of 22 A and a voltage rating of 450 V AC.

The housing is made from grey UL94-V0 rated polycarbonate, providing robust mechanical and electrical insulation properties and is divisible for flexible use in various designs. The pressure clamp connection uses an M2.5 screw and zinc-plated steel clamp to ensure optimal contact and prevent loosening under vibration.

It supports a broad wire size range from 30 AWG (0.05 mm²) to 12 AWG (3.31 mm²), accommodating both solid and stranded wires, making it versatile for multiple industrial and electronic engineering applications.

The compact dimensions of 25 mm length, 8.5 mm width, and 15.5 mm depth make it suitable for dense PCB layouts without sacrificing performance or mechanical strength.

Compliance with standards such as VDE, RoHS, and cULus guarantees safety, environmental compliance, and international usability. Manufactured in Hungary, this terminal block offers consistent quality manufacturing.

This product finds extensive applications in industrial machinery, control systems, automotive electronics, power supplies, and other electronic assemblies requiring reliable terminal connections.

Supports current rating of up to 22 A providing robust connectivity. Compatible with wire sizes ranging from 30 AWG (0.05 mm²) to 12 AWG (3.31 mm²). Constructed with durable grey UL94-V0 polycarbonate housing that is divisible.

Equipped with pressure clamp system using M2.5 screws and zinc-plated steel clamps for secure electrical connections. Dimensions of 25 mm length, 8.5 mm width, and 15.5 mm depth optimize PCB space utilization. Rated for voltage up to 450 V AC meeting VDE, RoHS, and cULus standards.

Manufactured in Hungary ensuring consistent quality control. Ideal for industrial, electronic manufacturing, automotive, and power supply applications. Explore more advanced PCB Terminal Blocks and electronic components at EnvMart for various industrial and manufacturing needs.
