XP Power JCK 40W Isolated DC/DC Converter, 15V 2.67A, 18V-36V Input, 6-Pin DIP, Through Hole Mount, 92% JCK6024S12

XP Power JCK6024S12 is a high-performance, isolated DC/DC converter delivering 40 watts of regulated power output at 15 volts and 2.67 amperes. Designed for use in industrial, electronic, and manufacturing applications, it accepts a wide input voltage range of 18 to 36 volts DC, making it compatible with diverse power systems.

The device features a robust 6-pin Dual Inline Package (DIP) suitable for through-hole PCB mounting, providing mechanical stability and ease of installation. With a high isolation voltage rating of 1600 VDC, it ensures reliable electrical isolation between input and output, critical for safety and signal integrity in sensitive electronic environments.

Operating efficiently at up to 92%, the converter minimizes power loss and heat generation, supporting sustainable system design. It is rated for operation in harsh temperature conditions, ranging from -40°C to 70°C, enabling use in challenging environments such as telecommunications, industrial controls, and instrumentation.

Additional protections include overcurrent protection (OCP), overvoltage protection (OVP), and overtemperature protection (OTP), enhancing reliability and longevity. The 2:1 input voltage ratio flexibility and remote on/off capability allow designers to integrate the converter in complex power systems with control requirements.

The compact form factor (50.8 mm length, 50.8 mm width, and 10.16 mm depth) supports high power density and space-saving designs. The device’s MTBF rating of 330,000 hours reflects its durable and dependable nature required for mission-critical applications.

Offers a regulated 15V output voltage at 2.67A continuous current. Accepts wide input voltage range from 18V to 36V DC, suitable for varying power sources. Features a through-hole 6-pin DIP package ensuring reliable PCB mounting.

Provides 1600 VDC isolation voltage ensuring safety and noise reduction. Operates efficiently up to 92% with a compact size of 50.8 x 50.8 x 10.16 mm. Designed to function over a wide temperature range from -40°C to 70°C.

Includes protective features such as overcurrent, overvoltage, and overtemperature protection. Offers a 2:1 input ratio with remote on/off control capability. Mean Time Between Failures (MTBF) of 330,000 hours guarantees durability.

Manufactured in Taiwan ensuring quality and compliance with industrial standards. Explore more high-quality power management components and DC/DC Converters from XP Power in the EnvMart electronics catalog.
