Phoenix Contact COMBICON PTSM Series Pluggable Terminal Block, 3-Contact, 2.5 mm Pitch, 1 Row, 6A Current, 160V 1815277
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 160V |
| Brand | Phoenix Contact |
| Colour | White |
| Orientation | Straight |
| Current | 6A |
| Length | 5mm |
| Model | 1815277 |
| Depth | 9.5mm |
| Width | 9.2mm |
| Housing Material | Polybutylene Terephthalate |
| Series | COMBICON PTSM |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Standards/Approvals | CHINA RoHS, CSA, cULus, EU REACH SVHC, EU RoHS |
| Number of Contacts | 3 |
| Connector Gender | Male |
| Maximum Wire Size mm² | 0.5mm² |
| Wire Connection Method | Solder |
Key Features
- Rated for 6A current and 160V voltage applications.
- Constructed with a durable polybutylene terephthalate housing for electrical insulation and stability.
- Designed with a single row configuration and straight orientation for easy PCB integration.
- Maximum wire size supported is 0.5 mm², suitable for small gauge wiring.
- Connector gender is male ensuring proper mating with female counterparts.
- Compact dimensions with a length of 5 mm, width of 9.2 mm, and depth of 9.5 mm allow for space-efficient PCB layouts.
- Compliant with CHINA RoHS, CSA, cULus, EU REACH SVHC, and EU RoHS standards ensuring environmental and safety adherence.
Product Description
Phoenix Contact 1815277 is a COMBICON PTSM series pluggable terminal block designed for electronic and electrical applications requiring secure and compact PCB connections. This 3-contact terminal block features a 2.5 mm pitch and 1-row configuration, providing an efficient footprint on circuit boards where space optimization is critical.
Constructed with a white polybutylene terephthalate housing, it ensures excellent electrical insulation, mechanical strength, and flame resistance. The connector is male with straight orientation, supporting soldered wire connections and accommodating maximum wire sizes of 0.5 mm².
With a voltage rating of 160V and a current rating of 6A, this terminal block supports low voltage and moderate current applications typically found in industrial control, instrumentation, and electronic equipment.
Its compact dimensions of 5 mm length, 9.2 mm width, and 9.5 mm depth facilitate integration into dense PCB assemblies.
Designed in compliance with international standards such as CHINA RoHS, CSA, cULus, EU REACH SVHC, and EU RoHS, it meets global regulatory requirements for environmental safety and product reliability.
Rated for 6A current and 160V voltage applications. Durable polybutylene terephthalate housing ensures excellent insulation. Straight orientation with male connector gender supports soldering connection method. Compact size supports space-saving PCB designs.
Complies with CHINA RoHS and international safety standards.
This pluggable terminal block is suitable for industrial machines, electronic instrumentation, control systems, and other electrical devices where secure and maintainable PCB connections are essential.
Explore a wide range of Phoenix Contact terminal blocks and connectors on EnvMart to meet diverse industrial and laboratory needs.
Explore more products in our Pluggable Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a current of 6A and a voltage of 160V, making it suitable for low voltage and moderate current applications.
This model features a pitch size of 2.5 mm, allowing for efficient PCB layouts.
The terminal block has compact dimensions of 5 mm in length, 9.2 mm in width, and 9.5 mm in depth.
It supports soldered wire connections and accommodates a maximum wire size of 0.5 mm².
The housing is constructed from polybutylene terephthalate, which provides excellent electrical insulation and mechanical strength.
Yes, it complies with several standards including CHINA RoHS, CSA, cULus, EU REACH SVHC, and EU RoHS.
It features a straight orientation and has a male connector gender, ensuring proper mating with female counterparts.
This model has 3 contacts, providing multiple connection points for wiring.
It is suitable for industrial machines, electronic instrumentation, control systems, and other electrical devices requiring secure PCB connections.
The 2.5 mm pitch allows for space-efficient PCB designs, making it ideal for applications where board space is limited.
The country of origin for this terminal block is India.
This terminal block belongs to the COMBICON PTSM series, known for its compact and efficient design.
