Wieland WIECON Series Pluggable Terminal Block 2-Contact 5 mm Pitch 1 Row 300 V 15 A Thermoplastic Housing Z5.530.0225.0
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 300V |
| Brand | Wieland |
| Colour | Grey |
| Orientation | Straight |
| Current | 15A |
| Length | 10mm |
| Model | Z5.530.0225.0 |
| Depth | 2.8mm |
| Housing Material | Thermoplastic |
| Series | WIECON |
| Number of Rows | 1 |
| Pitch | 5mm |
| Number of Contacts | 2 |
| Connector Gender | Male |
| Wire Connection Method | Solder |
Key Features
- Constructed with durable thermoplastic housing ensuring long-lasting performance.
- Rated for 15 A current and 300 V voltage applications.
- Features straight orientation male connector for secure solder wire connections.
- Compact dimensions of 10 mm length and 2.8 mm depth fit standard PCB layouts.
- Color-coded grey body aids in easy identification in electrical assemblies.
- Manufactured in Germany ensuring superior quality and standards compliance.
- Compatible with female cable mount terminals of nominal 2.5 mm² cable cross-section.
- Allows for easy pull-out terminal connections facilitating maintenance and wiring changes.
Product Description
Wieland Z5.530.0225.0 is a Pluggable Terminal Block from the WIECON Series designed for electronic and electrical connectivity applications. It provides a 2-contact interface at a 5 mm pitch arranged in a single row. The device's housing is made from thermoplastic material, ensuring both electrical insulation and mechanical durability.
This terminal block is rated for currents up to 15 A and voltages up to 300 V, making it suitable for various industrial, manufacturing, and automation systems requiring reliable and secure PCB connections. The male connector features a straight orientation designed for solder wire connections, facilitating robust and consistent electrical contact.
The compact dimensions of 10 mm length and 2.8 mm depth allow easy integration into printed circuit boards conforming to standard spacing. Its grey color coding supports straightforward visual identification during assembly or servicing.
Manufactured in Germany, the product meets stringent production quality criteria though it carries no specific listed approvals or certifications. It is compatible with female cable mount terminals supporting nominal cable cross-sections of 2.5 mm², enabling easy plug-in and pull-out connections for maintenance or wiring adjustments.
Constructed from high-grade thermoplastic housing for insulation and durability. Rated for 15 A current and 300 V voltage capacity suitable for diverse applications. Straight male connector orientation designed for solder wire connection.
Compact size facilitates integration in standard PCB designs. Grey coloration for easy identification on circuit boards. German manufacturing assuring quality and reliability. Allows pull-out terminal connections with compatible female cable mount terminals.
This Wieland WIECON Series Pluggable Terminal Block is ideal for applications in industrial automation, manufacturing electronics, power distribution, and electronic component assembly. Browse the Electronics Components category at EnvMart for more specialized connectors and terminal solutions.
Explore more products in our Pluggable Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for a maximum current of 15 A and a voltage of 300 V.
It features a 5 mm pitch and has 2 contacts arranged in a single row.
The housing is constructed from thermoplastic material, providing electrical insulation and mechanical durability.
The terminal block has a length of 10 mm and a depth of 2.8 mm, making it suitable for standard PCB layouts.
It utilizes a solder wire connection method, featuring a straight orientation male connector.
Yes, it is compatible with female cable mount terminals that support nominal cable cross-sections of 2.5 mm².
This product is manufactured in Germany, ensuring adherence to production quality standards.
The housing is color-coded grey, which aids in easy identification during assembly or servicing.
It is suitable for applications in industrial automation, manufacturing electronics, power distribution, and electronic component assembly.
This model has 1 row, accommodating a compact design for PCB integration.
This terminal block is part of the WIECON Series from Wieland.
The connector gender is male, designed for secure solder wire connections.
