Panasonic ECHU(X) 16 V dc 16V ac Film Capacitor 100nF Surface Mount ECHU1C104GX5
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 2.1mm |
| Length | 3.2mm |
| Model | ECHU1C104GX5 |
| Width | 2.5mm |
| Mount Type | Surface |
| Series | ECHU(X) |
| Maximum Operating Temperature | 125°C |
| Capacitance | 100nF |
| Standards/Approvals | RoHS |
| Rated AC Voltage | 16V ac |
| Rated DC Voltage | 16V dc |
Key Features
- Constructed from stacked metallised PPS film with mould-less design.
- Rated AC voltage of 16V and DC voltage of 16V for reliable performance.
- Compact and lightweight design for efficient PCB layout.
- Suitable for reflow soldering with a maximum operating temperature of 125°C.
- Low equivalent series resistance (ESR) improves circuit stability.
- Recommended for time-constant, oscillation, resonance, filtering, and audio circuits.
- Compliant with RoHS standards ensuring environmental safety.
- Ideal for industrial and electronic component manufacturing applications.
Product Description
Panasonic ECHU1C104GX5 is a high-quality film capacitor designed for surface mount applications featuring a capacitance of 100nF and rated for 16 V dc and 16 V ac. Constructed from stacked metallised polyphenylene sulfide (PPS) film with a mould-less design, these capacitors provide excellent reliability and long-term stability.
They exhibit low equivalent series resistance (ESR) which ensures optimum performance in oscillation, resonance, filtering, and audio circuit applications. The capacitors can withstand high temperature operation up to 125°C making them suitable for demanding industrial, electronic, and manufacturing environments. The ECHU(X) series capacitors are specifically designed for reflow soldering processes enhancing production efficiency and compact circuit board layout.
Measured dimensions of 3.2mm length, 2.5mm width, and 2.1mm height allow for space-saving designs. Panasonic ECHU1C104GX5 capacitors meet RoHS compliance standards providing environmental safety and usage confidence.
Constructed from stacked metallised PPS film with mould-less design. Rated AC and DC voltage of 16V for reliable operation. Compact size and lightweight suitable for surface mount technology. Supports reflow soldering process for efficient assembly.
Low ESR improves performance in time-constant and filtering circuits. Maximum operating temperature of 125°C for durable application. Environmentally compliant with RoHS certification. Compact dimensions of 3.2 x 2.5 x 2.1 mm footprint.
Ideal for electronics manufacturing, industrial, and audio applications.
This Panasonic ECHU1C104GX5 film capacitor is essential for designers and engineers seeking a reliable, compact, and efficient passive component for advanced electronic devices. Explore more Panasonic electronic components and Film Capacitors within the EnvMart catalog for comprehensive component sourcing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 100nF.
It is rated for both 16V AC and 16V DC.
The maximum operating temperature for this capacitor is 125°C.
The dimensions are 3.2mm in length, 2.5mm in width, and 2.1mm in height.
Yes, it is compliant with RoHS standards, ensuring environmental safety.
This model is designed for surface mount applications.
It is constructed from stacked metallised polyphenylene sulfide (PPS) film with a mould-less design.
It is recommended for use in time-constant, oscillation, resonance, filtering, and audio circuits.
This capacitor exhibits low equivalent series resistance (ESR), which improves circuit stability.
Yes, it is suitable for reflow soldering, enhancing production efficiency.
The country of origin for this model is India.
It belongs to the ECHU(X) series of capacitors.
