Molex 502584 Series Vertical Surface PCB Socket, 2-Contact, 1 Row, 1.5 mm Pitch Surface Mount 502584-0260
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 100V |
| Brand | Molex |
| Orientation | Vertical |
| Current | 2A |
| Mount Type | Surface |
| Contact Material | Copper Alloy |
| Series | 502584 |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 105°C |
| Sub Type | Wire-to-Board |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.5mm |
| Standards/Approvals | EU RoHS China RoHS Compliant Per - D(2021)4569-DC |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Connector System | Wire-to-Board |
| Stacking Height | 9.7mm |
Key Features
- This PCB socket features surface mount termination for efficient assembly.
- It supports a current rating of 2 A and voltage rating of 100 V.
- The vertical orientation and beige color body enhance mounting versatility.
- Operating temperature ranges from -40°C to 105°C for wide environmental tolerance.
- Constructed with copper alloy contacts plated with tin for durability and conductivity.
- Stacking height of 9.7 mm allows compact PCB design integration.
- Complies with EU RoHS and China RoHS environmental standards.
- Manufactured in Japan ensuring high-quality standards.
Product Description
Molex 502584-0260 vertical surface PCB socket is designed for wire-to-board applications requiring reliable electrical connections with 2 contacts arranged in a single row and a 1.5 mm pitch spacing. It features surface mount technology termination and a vertical orientation ensuring efficient PCB assembly and compact design.
This socket is rated for 2 amperes current and 100 volts voltage, supporting low to moderate power applications. Its operating temperature range of -40°C up to 105°C accommodates demanding industrial and commercial environments.
Constructed with high-quality copper alloy contacts plated with tin, this connector ensures excellent conductivity and resistance to corrosion. The stacking height of 9.7 mm offers design flexibility in multi-layer PCB assemblies.
Its beige-colored body complements the neutral appearance for standard electronic component integration. Molex 502584 series sockets conform to EU RoHS and China RoHS compliances, guaranteeing environmentally safe materials and manufacturing processes.
Originating from Japan, this product maintains high manufacturing standards suitable for electronics manufacturing, industrial control, telecommunications, automotive, and other sectors requiring robust PCB interconnect solutions.
This PCB socket features surface mount termination for efficient assembly. It supports a current rating of 2 A and voltage rating of 100 V. The vertical orientation and beige color body enhance mounting versatility. Operating temperature ranges from -40°C to 105°C for wide environmental tolerance.
Constructed with copper alloy contacts plated with tin for durability and conductivity. Stacking height of 9.7 mm allows compact PCB design integration. Complies with EU RoHS and China RoHS environmental standards. Manufactured in Japan ensuring high-quality standards.
Explore more reliable PCB Sockets and electronic components at EnvMart for your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket supports a current rating of 2 A and a voltage rating of 100 V, making it suitable for low to moderate power applications.
The operating temperature range for this model is from -40°C to 105°C, accommodating a variety of environmental conditions.
The stacking height of this PCB socket is 9.7 mm, allowing for compact integration in multi-layer PCB designs.
It features surface mount termination, which facilitates efficient assembly on printed circuit boards.
This socket has 2 contacts arranged in a single row, designed for wire-to-board applications.
The contacts are constructed from copper alloy and are plated with tin, ensuring good conductivity and resistance to corrosion.
This model has a vertical orientation, enhancing its versatility for various mounting configurations.
Yes, it complies with EU RoHS and China RoHS environmental standards, ensuring the use of safe materials.
This product is manufactured in Japan, adhering to high manufacturing standards suitable for various applications.
The pitch size of this socket is 1.5 mm, which is standard for many PCB applications.
This model is suitable for applications in electronics manufacturing, industrial control, telecommunications, and automotive sectors.
It uses a wire-to-board connector system, designed for reliable electrical connections in PCB assemblies.
