Microchip 16 bit Digital Signal Processor 70 MHz 256kB FLASH 44-Pin TQFP DSPIC33EP256MC204
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.05mm |
| Length | 10mm |
| Model | DSPIC33EP256MC204 |
| Width | 10mm |
| Mount Type | Surface |
| Series | DSPIC33EP256MC204 |
| Maximum Operating Temperature | 85°C |
| Package Type | TQFP |
| Minimum Operating Temperature | -40°C |
| Ram size | 32kB |
| ADC Resolution | 12bit |
| Timer Resolution | 32bit |
| Pin Count | 44 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 3.6V |
| Minimum Supply Voltage | 3V |
| Program Memory Size | 256kB |
| Maximum Clock Frequency | 70MHz |
| Number of Timers | 2 |
| Instruction Set Architecture | Harvard |
| Program Memory Type | FLASH |
| Number of ADCs | 1 |
| Device Million Instructions per Second | 70MIPS |
| Number of PWM Units | 3 |
| PWM Resolution | 16bit |
| ADC Channels | 9 |
| Number of PWM Channels | 6 |
| Numeric and Arithmetic Format | ALU |
Key Features
- Operates at a maximum clock frequency of 70 MHz.
- Features 256kB of FLASH program memory and 32kB RAM.
- Supports 70 MIPS performance with a 16-bit data bus.
- Includes 9 ADC channels with 12-bit ADC resolution.
- Equipped with 6 PWM channels and 2 timers with 32-bit resolution.
- Operating voltage range from 3 V to 3.6 V and temperature range from -40°C to 85°C.
- Automotive standard AEC-Q100 compliant for enhanced reliability.
Product Description
Microchip DSPIC33EP256MC204 is a high-performance 16 bit Digital Signal Processor operating at 70 MHz with 256kB FLASH program memory and 32kB RAM, packaged in a 44-Pin TQFP surface mount device. It utilizes a modified Harvard architecture and features an ALU numeric and arithmetic format optimized for embedded DSP applications.
This DSP is suited for precision motor control systems including brushless DC, permanent magnet synchronous, AC induction, and stepper motors. Its integrated peripherals provide 9 ADC channels at 12-bit resolution, 6 PWM channels across 3 PWM units, and 2 programmable timers with 32-bit resolution, making it ideal for energy-efficient, quiet operation and extended system life in industrial and automotive environments.
The device operates within a supply voltage range of 3 V to 3.6 V, can function in ambient temperatures from -40ºC to 85ºC, and complies with the automotive standard AEC-Q100 to ensure reliability under demanding conditions. The compact 10 mm square TQFP package with a height of 1.05 mm facilitates integration into dense PCB layouts.
Maximum clock frequency: 70 MHz for high-speed processing. Program memory size of 256kB FLASH ensures ample code space. 16-bit data bus width enhances processing efficiency. Supports 9 ADC channels with high 12-bit resolution for precise analog input measurements.
6 PWM channels enable complex motor control and modulation. Operating temperature range from -40°C to 85°C for harsh industrial environments. Automotive-grade AEC-Q100 certification for demanding applications. Compact 44-pin TQFP package dimensions suited for surface mount technology.
This DSP model DSPIC33EP256MC204 is a versatile solution ideal for industrial automation, automotive motor control, and advanced signal processing applications requiring robust performance and peripheral integration. Browse EnvMart for additional Microchip processors and digital signal controllers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum clock frequency of this model is 70 MHz, enabling high-speed processing for various applications.
It features a program memory size of 256kB FLASH, providing ample space for code storage.
This model supports 9 ADC channels, each with a 12-bit resolution for precise analog input measurements.
The operating voltage range is from 3 V to 3.6 V, suitable for various electronic applications.
This model has a compact size of 10 mm x 10 mm with a height of 1.05 mm, designed for surface mount technology.
It includes 6 PWM channels across 3 PWM units, which are essential for motor control applications.
The operating temperature range is from -40°C to 85°C, making it suitable for harsh industrial environments.
It complies with the automotive standard AEC-Q100, ensuring enhanced reliability for automotive applications.
This digital signal processor is equipped with 2 programmable timers that have a 32-bit resolution.
It utilizes a modified Harvard architecture, optimized for embedded DSP applications.
This model features a RAM size of 32kB, providing sufficient memory for processing tasks.
It comes in a 44-pin TQFP (Thin Quad Flat Package), which is suitable for surface mounting on PCBs.
