Samtec IPBT Series Through Hole 18-Contact, 2-Row Shrouded Straight PCB Header, 4.19 mm Pitch IPBT-109-H1-T-D-GP
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Model | IPBT-109-H1-T-D-GP |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | IPBT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 4.19mm |
| Contact Plating | Gold or Tin |
| Number of Contacts | 18 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
Key Features
- Constructed with liquid crystal polymer housing for durability.
- Gold or tin plated copper alloy contacts ensure reliable conductivity.
- Designed for through hole mounting on PCB.
- Operates reliably between -55°C to 125°C temperature range.
- Features straight orientation for easy board connections.
- Individually shrouded contacts provide isolation and protection.
- Offers solder termination type with male contact gender.
- Complies with standard board-to-board connector systems.
Product Description
Samtec IPBT-109-H1-T-D-GP is a high-quality PCB header designed for industrial and electronic applications requiring robust board-to-board connectivity. This through-hole mounted, 2-row connector features 18 contacts spaced at a precise 4.19 mm pitch, ensuring reliable electrical connections between printed circuit boards.
The header's housing is manufactured from liquid crystal polymer, providing excellent mechanical strength and thermal stability up to 125°C while operating effectively as low as -55°C. Each contact is individually shrouded, enhancing insulation and preventing accidental shorts during assembly and operation.
The contacts are made from a copper alloy and plated with gold or tin, which guarantees superior conductivity and corrosion resistance for long-term performance in demanding environments. Intended for male contact gender applications, the device utilizes solder termination, streamlining the assembly process onto PCBs.
This PCB header supports straight orientation and through-hole mounting, making it compatible with standard electronic manufacturing practices and ensuring ease of integration within diverse electronic circuitry.
Ideal for deployment in industrial electronics, telecommunications equipment, automotive electronics, and other commercial electronic assemblies, the Samtec IPBT-109-H1-T-D-GP delivers dependable mechanical and electrical performance. Its design balances ruggedness with compact form factor for efficient board utilization.
Constructed with liquid crystal polymer housing for durability. Gold or tin plated copper alloy contacts ensure reliable conductivity. Designed for through hole mounting on PCB. Operates reliably between -55°C to 125°C temperature range.
Features straight orientation for easy board connections. Individually shrouded contacts provide isolation and protection. Offers solder termination type with male contact gender. Complies with standard board-to-board connector systems.
Explore more in the PCB Headers category on EnvMart for compatible connectors, headers, and interface components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB header is 4.19 mm, ensuring precise spacing for reliable electrical connections.
It operates reliably between -55°C and 125°C, making it suitable for a variety of environments.
This model features 18 contacts, allowing for multiple connections in a compact design.
The housing is constructed from liquid crystal polymer, which provides excellent mechanical strength and thermal stability.
It utilizes solder termination, which simplifies the assembly process onto printed circuit boards.
The IPBT-109-H1-T-D-GP features male contact gender, designed for compatibility with corresponding female connectors.
The contacts are plated with either gold or tin, ensuring reliable conductivity and corrosion resistance.
It is designed for through hole mounting, which is a standard method for securing components on printed circuit boards.
This model features a straight orientation, facilitating easy connections to the PCB.
It is ideal for use in industrial electronics, telecommunications equipment, automotive electronics, and other commercial electronic assemblies.
The IPBT-109-H1-T-D-GP has 2 rows, allowing for a compact arrangement of contacts.
The country of origin for this product is India, indicating its manufacturing location.
