Samtec 4-Contact 1 Row 2 mm Pitch Straight Surface Mount PCB Socket SMM-104-02-S-S-K-TR

The Samtec SMM-104-02-S-S-K-TR is a specialized PCB socket designed for surface mounting on printed circuit boards, providing secure and reliable electrical connections in electronics assemblies. This model belongs to the SMM series and features a single row of 4 contacts with a 2 mm pitch, gratifying compact design requirements.

Manufactured with a housing composed of robust Liquid Crystal Polymer, this socket ensures both mechanical strength and excellent thermal stability. The contacts are made from beryllium copper alloy plated selectively with 0.000762 mm gold in the contact area, which guarantees excellent conductivity and corrosion resistance over time.

Designed as a female contact socket for board-to-board connector systems, it offers a current rating of 3.2 amperes at a voltage of up to 350 volts. The straight orientation and surface mount termination type make it ideally suited for automated PCB assembly processes, increasing manufacturing efficiency.

The SMM-104-02-S-S-K-TR operates reliably across a broad temperature range from minus 55 degrees Celsius to 125 degrees Celsius, suitable for demanding industrial and electronic applications. It is supplied in tape and reel packaging, compatible with pick and place machine assembly lines.

Uses a durable Liquid Crystal Polymer housing for high performance under stress. Selective gold plating on contacts ensures low contact resistance and durability. Supports 3.2 A current at 350 V voltage level for reliable electrical operations.

Single row, 4-contact design with 2 mm pitch optimizes space on PCB. Female gender contacts for board-to-board connection systems. Operates within -55°C to 125°C suitable for industrial electronics environments. Surface mount termination with straight orientation for efficient PCB integration.

Packaged in tape and reel for automated assembly processes.

This PCB socket is compatible with various electronics manufacturing, testing, and repair applications across industrial, commercial, and laboratory environments. Its precise mechanical and electrical specifications make it a dependable component for board-to-board interface solutions.
