Vishay 2225 Shielded Surface Mount Inductor with Metal Composite Core 4.7 μH ±20% 6.5 A Idc IHLP2525EZEK4R7M01
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 5mm |
| Length | 6.7mm |
| Model | IHLP2525EZEK4R7M01 |
| Depth | 5mm |
| Series | IHLP |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 4.7μH |
| Standards/Approvals | JEDEC, RoHS |
| Package/Case | 2225 |
| Maximum DC Current | 6.5A |
| Maximum DC Resistance | 30.3mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Shielded |
Key Features
- Constructed with a metal composite core for soft saturation and high transient current handling.
- Shielded design reduces electromagnetic interference for stable inductance.
- Compact 2225 package with dimensions 6.7 mm length, 5 mm height, and 5 mm depth.
- Operates reliably from -55°C to 125°C with RoHS and JEDEC compliance.
- Maximum DC resistance is 30.3 mΩ ensuring efficient performance at high currents.
- Surface mount termination style compatible with automated PCB assembly.
- Moulded construction enhances durability and mechanical strength.
- Suitable for power electronics applications requiring stable inductors under high current spikes.
Product Description
The Vishay IHLP2525EZEK4R7M01 is a high-performance 2225 shielded surface mount inductor featuring a metal composite core with an inductance of 4.7 μH and ±20% tolerance. Designed to handle maximum DC currents up to 6.5 A, it ensures stable operation under transient current spikes without saturation due to its powdered iron composition.
This inductor measures 6.7 mm in length, 5 mm in height, and 5 mm in depth, making it compact for surface mount PCB applications. It has a maximum DC resistance of 30.3 mΩ, which contributes to high efficiency by minimizing power losses. Its shielded construction confines the magnetic field, reducing electromagnetic interference in sensitive electronic circuits.
Operating over a temperature range of -55°C to 125°C, the IHLP2525EZEK4R7M01 complies with JEDEC and RoHS standards, including halogen-free materials, ensuring compliance with environmental regulations. The moulded design adds mechanical durability suitable for industrial and commercial electronic assemblies.
Ideal for power electronics, voltage regulation, DC-DC converters, and filtering applications, this Vishay Surface Mount Inductor delivers consistent performance in demanding conditions. Its metal composite core provides soft saturation characteristics and excellent thermal stability.
Constructed with metal composite core for high current transient handling. Shielded to minimize electromagnetic interference. Compact 2225 package dimensions for space-efficient PCB design. Wide operating temperature range from -55°C to 125°C.
Low DC resistance for improved efficiency under load. Surface mount compatible termination style. RoHS and JEDEC compliance ensure environmental and quality standards. Moulded body for enhanced physical resilience.
This inductor is suitable for industrial, commercial, and power electronics manufacturing environments requiring reliable, precision inductors. Find more Vishay electronic components and related products on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 4.7 μH with a tolerance of ±20%.
It can handle a maximum DC current of 6.5 A.
The dimensions of the inductor are 6.7 mm in length, 5 mm in height, and 5 mm in depth.
The maximum DC resistance is 30.3 mΩ, which aids in efficient performance at high currents.
It operates reliably over a temperature range from -55°C to 125°C.
The inductor features a metal composite core that provides soft saturation characteristics.
Yes, it complies with JEDEC and RoHS standards, ensuring it meets environmental regulations.
The termination style is surface mount, making it compatible with automated PCB assembly.
It is suitable for power electronics applications such as voltage regulation, DC-DC converters, and filtering.
The shielded construction of this inductor helps minimize electromagnetic interference, ensuring stable inductance.
This inductor is manufactured in India.
The series name of this inductor is IHLP.
