Vishay 7.67 V Single Zener Diode 500 mW Surface Mount 2-Pin DO-219AC MicroSMF PLZ7V5C-HG3_A/H

Free Delivery in India | Lowest Global Shipping Charges

Vishay 7.67 V Single Zener Diode 500 mW Surface Mount 2-Pin DO-219AC MicroSMF PLZ7V5C-HG3_A/H

Name: Vishay 7.67 V Single Zener Diode 500 mW Surface Mount 2-Pin DO-219AC MicroSMF PLZ7V5C-HG3_A/H
Brand: Vishay
SKU: 170483
Price: 0.07 USD
Availability: InStock



Category Zener Diodes Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	0.6mm
Length	2.5mm
Model	PLZ7V5C-HG3_A/H
Mount Type	Surface
Series	PLZ
Maximum Operating Temperature	150°C
Package Type	DO-219AC (MicroSMF)
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	20mA
Maximum Reverse Leakage Current	500nA
Nominal Zener Voltage Vz	7.67V
Zener Type	General Purpose
Maximum Zener Impedance	8Ω

Key Features

Nominal Zener voltage of 7.67 V ensures precise voltage regulation.
Maximum power dissipation rating of 500 mW supports reliable operation.
Packaged in low profile 2-pin DO-219AC (MicroSMF) surface mount form factor.
Maximum reverse leakage current of 500 nA minimizes power loss.
Operational temperature range from -55°C to 150°C supports harsh environments.
Maximum Zener impedance of 8 ohms ensures stable voltage regulation.
Automotive standard compliant with AEC-Q101 for high reliability.
Low leakage current and excellent stability enhance performance.

Product Description

Vishay PLZ7V5C-HG3_A/H is a single Zener diode designed for voltage regulation applications, offering a nominal Zener voltage of 7.67 V and a power dissipation capacity of 500 mW. This device is housed in a compact DO-219AC (MicroSMF) surface-mount package with 2 pins, suitable for space-constrained electronic designs.

The silicon planar diode exhibits low leakage current and excellent stability, ensuring reliable performance in electronic circuits across various industrial and automotive applications. Its maximum reverse leakage current is limited to 500 nA, and it maintains a maximum Zener impedance of 8 Ω for steady voltage regulation.

Operational temperature ranges between -55°C and 150°C, making it well-suited for demanding environments, and compliance with the AEC-Q101 automotive standard underscores its robust quality. The diode supports wave and reflow solder processes withstanding soldering temperatures up to 260°C.

This diode is ideal for use in voltage regulation, voltage reference in power supplies, and protection circuits in industrial, automotive, and electronic manufacturing sectors. Nominal Zener voltage of 7.67 V ensures consistent voltage control.

500 mW maximum power dissipation facilitates stable operation. Compact DO-219AC MicroSMF package for surface mounting applications. Low leakage current and high temperature soldering capability. Wide operating temperature range from -55°C to 150°C.

Compliance with RoHS, IEC 61760-1, IEC 61000-4-2 standards. Meets AEC-Q101 automotive reliability standard. Excellent stability for stable electronic circuit performance. Wave and reflow solderable with 260°C high temperature soldering.

Designed for electronic components, power connectors, and semiconductor uses. Explore more Zener Diodes and electronic components in the Vishay product range on EnvMart for professional industrial and electronics applications.
