Texas Instruments Brushed DC Motor Driver IC 36 V 1 A 16-Pin PDIP L293NE

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments Brushed DC Motor Driver IC 36 V 1 A 16-Pin PDIP L293NE

Name: Texas Instruments Brushed DC Motor Driver IC 36 V 1 A 16-Pin PDIP L293NE
Brand: Texas Instruments
SKU: 166002
Price: 8.86 USD
Availability: InStock



Category Motor Driver IC Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	4.57mm
Length	19.8mm
Model	L293NE
Width	6.35mm
Motor Type	Brushed DC Motor
Mount Type	Through Hole
Series	L293
Configuration	Bipolar
Output Current	2A
Maximum Operating Temperature	70°C
Package Type	PDIP
Minimum Operating Temperature	0°C
Pin Count	16
Maximum Collector Emitter Voltage Vceo	36V
Maximum Supply Voltage	36V
Minimum Supply Voltage	4.5V
Supply Current	6mA
Maximum IGBT Collector Current	1A

Key Features

Supports motor voltages from 4.5 V up to 36 V for versatile applications.
Provides output current capability of 2 A for controlling various motors.
Bipolar configuration suitable for driving relays, solenoids, and stepping motors.
Designed with through hole mounting for easy PCB integration.
Operates under ambient temperatures from 0°C to 70°C ensuring durability.
Compact dimensions of 19.8 mm length, 6.35 mm width, and 4.57 mm height.
Consumes a low quiescent supply current of 6 mA for efficiency.
Non-automotive standard device ideal for general industrial motor control.

Product Description

Texas Instruments L293NE is a 16-pin PDIP packaged motor driver IC designed for driving Brushed DC motors. Operating at voltages from 4.5 V to 36 V, it supports output currents up to 2 A, making it ideal for a wide range of actuators including relays, solenoids, and bipolar stepping motors.

This bipolar configured device ensures bidirectional control of motors with a maximum collector emitter voltage of 36 V and maximum IGBT collector current of 1 A. Its through-hole mounting package facilitates robust and easy PCB assembly.

The L293NE operates reliably within a temperature range of 0°C to 70°C and features a low supply current of 6 mA, enhancing energy efficiency in embedded designs. Its compact size (19.8 mm length, 6.35 mm width, 4.57 mm height) makes it suitable for space-constrained applications.

This motor driver IC is widely used in industrial, robotics, and automation environments for controlling brushed DC motors and other inductive loads. It provides a sturdy and efficient interface between low-level microcontroller signals and high-power motor loads.

Supports motor voltages from 4.5 V to 36 V. Output current capability of 2 A for diverse motor applications. Bipolar configuration for bidirectional motor control. Through hole mounting type with PDIP package. Operating temperature range of 0°C to 70°C for industrial robustness.

Low supply current of 6 mA for power efficiency. Compact dimensions suitable for embedded and industrial systems. Ideal for robotics, automation, and industrial motor control uses.

The enclosed package ensures secure mounting and easy integration on printed circuit boards. Texas Instruments' L293NE is a proven solution for efficient motor driving requiring precise and adaptable current control in diverse applications.

Explore more Motor Driver ICs and electronic components at EnvMart to support your industrial automation and embedded system needs.
