Wurth Elektronik 2433 Series PCB Terminal Block, 10-Contact, 3.81 mm Pitch, Through Hole, Horizontal 691243310010

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 2433 Series PCB Terminal Block, 10-Contact, 3.81 mm Pitch, Through Hole, Horizontal 691243310010

Name: Wurth Elektronik 2433 Series PCB Terminal Block, 10-Contact, 3.81 mm Pitch, Through Hole, Horizontal 691243310010
Brand: Wurth Elektronik
SKU: 159238
Price: 6.97 USD
Availability: InStock



Category PCB Terminal Block Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Italy
Voltage	130V ac
Brand	Wurth Elektronik
Colour	Green
Orientation	Horizontal
Current	10A
Length	38.1mm
Depth	9.1mm
Width	7.3mm
Mount Type	Through Hole
Series	2433
Number of Rows	1
Pitch	3.81mm
Standards/Approvals	VDE, RoHS, cULus
Number of Contacts	10
Minimum Wire Size mm²	0.05mm²
Maximum Wire Size mm²	1.31mm²
Minimum Wire Size AWG	30AWG
Maximum Wire Size AWG	16AWG

Key Features

Designed for horizontal orientation and single row configuration.
Supports current up to 10 Amperes at 130V AC voltage rating.
Accommodates wire sizes from 30 AWG to 16 AWG, or 0.05 mm² to 1.31 mm².
Constructed with green color coded housing for easy identification.
Compliant with VDE, RoHS, and cULus standards for quality and safety.
Compact dimensions measuring 38.1 mm length, 7.3 mm width, and 9.1 mm depth.
Made in Italy, ensuring high manufacturing standards.

Product Description

Wurth Elektronik 691243310010 PCB Terminal Block is a reliable electrical connector designed for use in electronic and electrical circuits where secure and expandable connections are required.

This terminal block features 10 individual contacts set in a single row layout with a 3.81 mm pitch between pins, accommodating a wide range of wire gauges from 30 AWG (0.05 mm²) to 16 AWG (1.31 mm²). The standard through-hole mounting ensures robust attachment to printed circuit boards (PCBs), ideal for applications demanding high mechanical strength.

Rated to conduct up to 10 Amperes of current at an AC voltage rating of 130V, this green-colored terminal block is engineered to withstand moderate electrical loads commonly found in industrial, commercial, and laboratory electronic equipment.

Manufactured in Italy, it adheres to international safety and environmental standards including VDE, RoHS, and cULus certifications, assuring user confidence and regulatory compliance.

The compact form factor, with physical dimensions of 38.1 mm in length, 7.3 mm in width, and 9.1 mm in depth, allows integration into densely populated circuit boards without sacrificing connection reliability.

Designed for horizontal orientation and single row configuration. Supports current up to 10 Amperes at 130V AC voltage rating. Accommodates wire sizes from 30 AWG to 16 AWG, or 0.05 mm² to 1.31 mm². Constructed with green color coded housing for easy identification.

Compliant with VDE, RoHS, and cULus standards for quality and safety. Compact dimensions measuring 38.1 mm length, 7.3 mm width, and 9.1 mm depth. Made in Italy, ensuring high manufacturing standards.

This terminal block is well suited for industrial automation, power connectors in electronic assemblies, circuit boards in measuring and testing instruments, HVAC control panels, and general manufacturing applications requiring secure PCB connectivity solutions.
