TDK Wirewound Shielded Surface Mount Inductor with Ferrite Core 1 μH ±20% 455 mA 1008 Case NLFV25T-1R0M-EF
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | TDK |
| Height | 1.8mm |
| Operating Temperature Range | - 40 to +105°C (including self-temperature rise) |
| Length | 2.5mm |
| Model | NLFV25T-1R0M-EF |
| Depth | 2mm |
| Packaging | Tape & Reel |
| Series | NLFV-EF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 1μH |
| Standards/Approvals | RoHS |
| Package/Case | 1008 |
| Maximum DC Current | 455mA |
| Maximum DC Resistance | 80mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 2.52MHz |
| Inductor Construction | Wirewound |
Key Features
- Compact 1008 case size suitable for surface mount applications.
- Inductance of 1 μH with ±20% tolerance ensures stable electrical performance.
- Maximum DC current rating of 455 mA for reliable operation.
- Magnetic shielding with ferrite powder reduces electromagnetic interference.
- Operating temperature range from -40°C to 105°C including self-temperature rise.
- Maximum DC resistance of 80 mΩ minimizes power losses.
- Wirewound ferrite core construction for high reliability and durability.
- Tape and reel packaging supports automated manufacturing processes.
Product Description
TDK NLFV25T-1R0M-EF wirewound shielded surface mount inductor integrates a ferrite core to deliver an inductance of 1 μH with a tolerance of ±20%. Rated for a maximum DC current of 455 mA, this component is designed for reliable decoupling and signal filtering in electronic circuits.
The inductor comes in a 1008 package case measuring 2.5 mm in length, 1.8 mm in height, and 2 mm in depth, making it suitable for compact surface mount device (SMD) applications. It features high shielding by embedding ferrite powder in the resin mold to minimize electromagnetic interference, enhancing circuit stability.
Operating temperature ranges between -40°C and 105°C, accommodating demanding environments including self-temperature rise effects. The maximum DC resistance is limited to 80 mΩ to ensure efficient current flow with minimal losses.
Manufactured in Japan with RoHS compliance, the NLFV25T-1R0M-EF is molded with wirewound construction for durability and consistent electrical characteristics. Its termination style is optimized for surface mounting on printed circuit boards.
Typical applications include smart meters, audio-video equipment, xDSL devices, mobile base stations, and various industrial communication equipment, where noise suppression and signal integrity are critical.
This inductor is tape and reel packaged for automated assembly processes. Its ferrite core and shielded construction provide enhanced magnetic performance and EMI reduction. The device supports a maximum self-resonant frequency of 2.52 MHz for various frequency applications.
Compliance with international standards and certifications such as RoHS underlines its quality and environmental safety.
The component is ideal for designers and engineers looking for a trusted inductor solution in industrial, communication, and consumer electronics applications. Explore the full range of TDK inductors for your next project on EnvMart.
Explore more products in our Surface Mount Inductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 1 μH with a tolerance of ±20%.
The maximum DC current rating for this inductor is 455 mA, ensuring reliable operation in various applications.
The operating temperature range is from -40°C to 105°C, including self-temperature rise effects.
The dimensions of the 1008 package case are 2.5 mm in length, 1.8 mm in height, and 2 mm in depth.
The ferrite core construction enhances magnetic performance and reduces electromagnetic interference, improving circuit stability.
The maximum DC resistance is limited to 80 mΩ, which helps minimize power losses during operation.
This inductor supports a maximum self-resonant frequency of 2.52 MHz, suitable for various frequency applications.
It is packaged in tape and reel format, which supports automated manufacturing processes.
The component is RoHS compliant, ensuring it meets environmental safety standards.
The termination style is optimized for surface mounting on printed circuit boards.
This inductor is manufactured in Japan, ensuring high-quality production standards.
