Samtec CLP Series Straight Surface PCB Socket, 16-Contact, 2 Row, 1.27 mm Pitch, 3.4A Current, 395V Voltage CLP-108-02-F-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec CLP Series Straight Surface PCB Socket, 16-Contact, 2 Row, 1.27 mm Pitch, 3.4A Current, 395V Voltage CLP-108-02-F-D

Name: Samtec CLP Series Straight Surface PCB Socket, 16-Contact, 2 Row, 1.27 mm Pitch, 3.4A Current, 395V Voltage CLP-108-02-F-D
Brand: Samtec
SKU: 154789
Price: 2.96 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	United States
Voltage	395V
Brand	Samtec
Orientation	Straight
Current	3.4A
Model	CLP-108-02-F-D
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Bronze
Series	CLP
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Rugged Reliable Dual Wipe Socket Strip
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	16
Connector System	Board-to-Board

Key Features

The socket supports a current rating of 3.4A and a voltage rating of 395V.
It uses a rugged reliable dual wipe socket strip design for enhanced durability.
Termination is by soldering suitable for surface mount applications.
Housing is made of liquid crystal polymer providing excellent thermal and mechanical stability.
Contacts are bronze with gold plating ensuring superior conductivity and corrosion resistance.
It operates reliably at temperatures from -55°C to 125°C.
The connector has a straight orientation for easy PCB integration.
The product is made in the United States, ensuring high manufacturing standards.

Product Description

Samtec CLP-108-02-F-D is a high-quality straight surface PCB socket designed for electronic components requiring a robust and reliable connection. This series features 16 contacts arranged in two vertical rows with a 1.27 mm pitch, supporting board-to-board connector systems.

The socket is rated for a current of 3.4 amperes and a voltage up to 395 volts, making it suitable for moderate power electronic applications. The termination type is solder, tailored for surface mount technology (SMT) ensuring strong mechanical and electrical bonding on printed circuit boards.

Constructed with a liquid crystal polymer housing, this socket offers excellent mechanical strength and thermal stability in a wide temperature range from -55°C to 125°C, allowing performance in harsh industrial or commercial environments.

The dual wipe Tiger Claw™ contact design ensures reliable electrical contact with enhanced durability over extended product life. Contact materials consist of bronze with a gold plating to enhance conductivity and resist corrosion, vital for maintaining signal integrity over repeated mating cycles.

Supports a 16-contact dual row configuration with 1.27 mm pitch. Designed for surface mount board-to-board connector applications. Housed in robust liquid crystal polymer for thermal and mechanical excellence. Features gold-plated bronze contacts for superior conductivity.

Operates within a temperature range of -55°C to 125°C. Current rated up to 3.4A and voltage rating up to 395V. Manufactured in the United States with high quality standards.

This PCB socket is ideal for industries including telecommunications, industrial control equipment, consumer electronics, and automotive electronics where dependable connection and longevity are critical.

Explore a broad range of PCB Sockets and connectors at EnvMart for various electronic assembly and prototyping needs.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This socket supports a current rating of 3.4A and a voltage rating of 395V, making it suitable for moderate power electronic applications.

The CLP-108-02-F-D features a 1.27 mm pitch with 16 contacts arranged in two vertical rows.

It uses a solder termination type, which is designed for surface mount technology (SMT), ensuring strong mechanical and electrical bonding on printed circuit boards.

The housing is made of liquid crystal polymer, while the contacts are bronze with gold plating for enhanced conductivity and corrosion resistance.

This socket operates reliably within a temperature range of -55°C to 125°C, allowing it to perform in harsh industrial or commercial environments.

The connector has a straight orientation, which facilitates easy integration onto a PCB.

It is suitable for various industries including telecommunications, industrial control equipment, consumer electronics, and automotive electronics, where dependable connection and longevity are critical.

This model supports a board-to-board connector system, making it ideal for connecting two printed circuit boards together.

The CLP-108-02-F-D has 2 rows and a total of 16 contacts, designed for reliable electrical connections.

It features a dual wipe Tiger Claw™ contact design, which ensures reliable electrical contact and enhances durability over extended product life.

This PCB socket is manufactured in the United States, ensuring adherence to high manufacturing standards.

This socket is designed for surface mount board-to-board connector applications, making it suitable for various electronic assembly and prototyping needs.
