Wurth Elektronik DC Input 4-Channel Optocoupler Phototransistor Surface Mount 4-Pin DIP 1.4V 60mA 5000Vrms 140816142200
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Packaging | Tube |
| Mount Type | Surface |
| Output type | Phototransistor |
| Series | WL-OCPT |
| Maximum Operating Temperature | 110°C |
| Package Type | DIP |
| Minimum Operating Temperature | -55°C |
| Maximum input current | 60mA |
| Number Of Channels | 4 |
| Standards/Approvals | CoC, IEC 61249-2-21, JEDEC JS709B, REACH, RoHS, VDE |
| Maximum Forward Voltage | 1.4V |
| Number of Pins | 4 |
| Input Current Type | DC |
| Typical Rise Time | 3μs |
| Maximum Current Transfer Ratio | 260% |
| Typical Fall Time | 4μs |
| Minimum Current Transfer Ratio | 130% |
Key Features
- Four-channel configuration supporting multiple simultaneous inputs.
- Surface mount package ensures easy PCB integration with 4-pin DIP form factor.
- Phototransistor output type with high current transfer ratios enhances signal fidelity.
- Maximum input forward voltage of 1.4V allows efficient DC input handling.
- High isolation voltage of 5000 Vrms ensures robust operational safety.
- Operating temperature range from -55°C to 110°C suits industrial environments.
- Typical rise and fall times of 3μs and 4μs enable fast switching.
- Supports input currents up to 60mA and power dissipation of 200mW.
Product Description
Wurth Elektronik 140816142200 DC Input 4-Channel Optocoupler is a compact, high-performance phototransistor device designed for surface mounting. Featuring a 4-pin DIP package with dimensions of 6.5mm x 4.58mm x 3.5mm (L x W x H), it facilitates reliable isolation between control circuits and high-voltage systems. The device is capable of handling a collector-emitter voltage of up to 80V and input currents up to 60mA with a power dissipation of 200mW, making it ideal for electronic load control in industrial automation and measurement equipment.
Its typical rise and fall times of 3μs and 4μs enable swift signal response, ensuring efficiency in data communications and sensor applications. The Wurth Elektronik optocoupler series WL-OCPT is designed for robust performance, providing excellent stability of internal isolation and a stable current transfer ratio through its operational range. Its high isolation voltage of 5000 Vrms offers excellent protection and reduces electrical noise, enhancing system reliability in harsh industrial and laboratory environments.
Conforming to standards such as CoC, IEC 61249-2-21, JEDEC JS709B, REACH, RoHS, and VDE, this device meets stringent quality and environmental demands. Typical applications include control of various load types, measurement equipment, data communication systems, power supply sensors, and other industrial controls.
Four channels facilitate multiple simultaneous monitoring or control inputs. Surface mount design compatible with standard PCB manufacturing. Phototransistor output provides amplification suitable for microcontroller interfacing.
Robust electrical isolation supports safe operation in high-voltage environments. Wide operating temperature range suits industrial and commercial conditions. Standards compliance ensures environmental safety and global acceptance.
This Wurth Elektronik optocoupler is a critical component for engineers designing industrial control, automation, and sensor applications, delivering a reliable and fast optoelectronic switching solution.
Explore more industrial-grade electronic components and Optocouplers in EnvMart's comprehensive catalog to support your project requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input forward voltage for this model is 1.4V, allowing efficient handling of DC inputs.
It has a high isolation voltage of 5000 Vrms, ensuring robust operational safety in high-voltage environments.
The operating temperature range is from -55°C to 110°C, making it suitable for various industrial conditions.
This unit features a four-channel configuration, allowing for multiple simultaneous inputs.
The typical rise time is 3μs and the typical fall time is 4μs, enabling fast switching capabilities.
It provides a phototransistor output type, which is suitable for amplification and interfacing with microcontrollers.
It can handle a maximum input current of 60mA, supporting various applications in control systems.
The package dimensions are 6.5mm x 4.58mm x 3.5mm (L x W x H), designed for surface mounting.
It complies with several standards including CoC, IEC 61249-2-21, JEDEC JS709B, REACH, RoHS, and VDE.
The maximum power dissipation is 200mW, suitable for various electronic applications.
It features a surface mount design, which facilitates easy integration into PCBs.
The maximum current transfer ratio is 260%, providing excellent signal fidelity in applications.
