Samtec CES Series Straight Through Hole PCB Socket 4 Contact 1 Row 2.54 mm Pitch Solder CES-104-01-G-S

Free Delivery in India | Lowest Global Shipping Charges

Samtec CES Series Straight Through Hole PCB Socket 4 Contact 1 Row 2.54 mm Pitch Solder CES-104-01-G-S

Name: Samtec CES Series Straight Through Hole PCB Socket 4 Contact 1 Row 2.54 mm Pitch Solder CES-104-01-G-S
Brand: Samtec
SKU: 154473
Price: 1.8 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	400V
Brand	Samtec
Orientation	Straight
Current	5.5A
Model	CES-104-01-G-S
Mount Type	Through Hole
Housing Material	Black Glass Filled Polyester
Contact Material	Bronze
Series	CES
Termination	Through-hole
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Socket Strip
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Standards/Approvals	RoHS
Contact Plating	Gold
Number of Contacts	4
Connector System	Board-to-Board
Contact System	Dual Leaf

Key Features

The socket features 4 contacts arranged in a single row for compact PCB layouts.
It has a standard pitch of 2.54 mm (.100 inch) suitable for many electronic applications.
Constructed with a black glass-filled polyester housing for durability and electrical insulation.
Contacts are made of bronze with gold plating to ensure reliable conductivity and corrosion resistance.
The termination is via soldering suitable for through-hole PCB mounting.
Rated for 5.5 A current and 400 V voltage handling capabilities.
It operates reliably in temperatures from -55°C up to 125°C.
Compatible with single and double row configurations up to 100 pins.

Product Description

Samtec CES-104-01-G-S is a precision Straight Through Hole PCB Socket designed for reliable board-to-board connectivity in electronic assemblies. This product features a 4-contact configuration in a single-row layout with a 2.54 mm pitch, making it ideal for compact electronic circuit designs.

The socket housing is made of black glass-filled polyester, providing high mechanical strength and excellent electrical insulation. Gold-plated bronze contacts ensure low resistance and durability even in demanding applications. The dual leaf contact system enhances connection stability.

The termination style is through-hole soldering, which offers a robust mechanical and electrical connection to the PCB. Rated for 5.5 A and 400 V, this socket can handle moderate power levels in electronic devices.

Operating temperature range from -55°C to 125°C makes it suitable for a broad array of industrial, consumer electronics, and telecommunications applications. Its flat orientation and straight mount type support straightforward PCB layout and assembly processes.

This product complies with RoHS standards, ensuring environmental safety and compliance with regulatory requirements. It is part of Samtec's CES series, known for high quality and performance.

The socket is designed for mounting on circuit boards via through-hole technology. It supports vertical, right-angle orientation for versatile board design. Suitable for single and double-row configurations with up to 100 pins, offering flexible connectivity options.

Durable construction materials assure long lifecycle and reliable signal transmission. Compliant with industry standards and environmental regulations.

Ideal applications include industrial electronics, telecommunications equipment, consumer electronics, and prototyping. Samtec's CES series sockets provide engineers with dependable interconnect solutions that combine mechanical and electrical reliability.

Explore more products in the PCB Sockets category for various mounting types and pin configurations suitable for diverse electronic designs at EnvMart.
