Bourns Plastic Encapsulated Varistor 150 pF Capacitance 5 A Clamping Current 360 V Clamping Voltage 220 V PV140K3225R2
Specifications
| Country of Origin | Slovenia |
|---|---|
| Brand | Bourns |
| Material | Plastic |
| THICKNESS | 3.4mm |
| Length | 8mm |
| Model | PV140K3225R2 |
| Depth | 3.4mm |
| Packaging | Tape & Reel |
| Mount Type | Surface |
| Series | PV |
| Energy Rating | 7.5J |
| Maximum Operating Temperature | 85°C |
| Capacitance | 150pF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 180V dc |
| Standards/Approvals | RoHS, UL |
| Package/Case | 3225 |
| Termination Style | Surface Mount |
| Maximum AC Voltage | 140V ac |
| Clamping Voltage VC | 360V |
| Clamping Current | 5A |
| Maximum Surge Current | 400A |
| Varistor Voltage | 220 V |
Key Features
- The varistor has a clamping voltage of 360 V and a varistor voltage of 220 V.
- It operates up to a maximum AC voltage of 140 V and maximum DC voltage of 180 V.
- The package size is 3225 with dimensions 8 mm length and 3.4 mm thickness and depth.
- The device features a maximum surge current rating of 400 A and an energy rating of 7.5 J.
- Its operating temperature range extends from -40°C to 85°C, suitable for demanding applications.
- The varistor has a UL 94 V-0 rated non-flammable thermoplastic encapsulation.
- It is designed for surface mount applications with tinned copper sheet contacts for easy soldering.
- Available in tape and reel packaging for automated pick-and-place assembly.
Product Description
Bourns PV140K3225R2 is a surface mount varistor designed to protect electronic equipment from transient voltage surges in low to medium voltage regions. The device features a capacitance of 150 pF and supports a clamping current of 5 A, making it suitable for precise surge protection applications. It has a clamping voltage of 360 V and a standard varistor voltage of 220 V, with maximum AC operation at 140 V and maximum DC operation at 180 V.
The product is encapsulated with UL 94 V-0 certified non-flammable thermoplastic, ensuring safety and durability in various industrial environments. Its compact 3225 package case measures 8 mm in length with a thickness and depth of 3.4 mm, optimized for surface mounting on PCBs. The contacts are made from tinned copper sheet, facilitating reliable soldering in automated manufacturing processes.
The varistor offers a maximum surge current capacity of 400 A and an energy rating of 7.5 joules, suitable for protecting sensitive components in electronic power supplies and circuits against high transient currents. Its operating temperature spans from -40°C to 85°C, enabling use in a wide range of industrial, laboratory, and commercial electronic applications.
Packaging is provided in tape and reel format, compatible with pick-and-place automation systems, enhancing manufacturing efficiency. Compliance with RoHS directives and UL standards guarantees environmentally sound and tested quality assurance.
This varistor is widely used in surge protection for power supplies, telecommunications equipment, consumer electronics, and industrial control circuits requiring reliable transient voltage suppression. Its plastic encapsulation and compact size make it ideal for space-constrained applications.
The device’s plastic-encapsulated design offers excellent protection against electrical surges. Surface mount termination supports advanced PCB assembly technology. UL 94 V-0 non-flammable thermoplastic encapsulation provides safety in diverse environments.
High surge and clamping current ratings ensure robust transient voltage suppression. RoHS compliance confirms adherence to environmental regulations.
Explore the full range of Varistors and surge protection solutions within the Electronics Components category at EnvMart for enhanced industrial and commercial electronic system protection.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The clamping voltage of this model is 360 V.
This varistor has a maximum surge current rating of 400 A.
It features a capacitance of 150 pF.
The package size is 3225, measuring 8 mm in length and 3.4 mm in thickness and depth.
The maximum operating temperature is 85°C.
It is encapsulated with UL 94 V-0 rated non-flammable thermoplastic material.
The energy rating of this varistor is 7.5 J.
The minimum operating temperature is -40°C.
It can handle a maximum DC voltage of 180 V.
This model supports surface mount termination style.
It complies with RoHS directives and UL standards.
This varistor is suitable for surge protection in power supplies, telecommunications equipment, and consumer electronics.
