Bourns Plastic Encapsulated Surface Mount Varistor 160 pF Capacitance 5 A Clamping Current 340 V Clamping PV130K3225R2

Bourns PV130K3225R2 is a plastic encapsulated surface mount varistor designed primarily to protect electronic equipment against voltage surges occurring in low and medium voltage applications. This model features a capacitance of 160 pF and a clamping current rating of 5 A with a clamping voltage of 340 V, ensuring effective transient voltage suppression.

The device is built with a non-flammable thermoplastic encapsulation that meets the UL 94 V-0 standard for fire safety, making it suitable for applications demanding high reliability. The contacts consist of tinned copper sheet, allowing for excellent solderability and stable electrical connections. The package type 3225 corresponds to an 8 mm length and 3.4 mm thickness and depth, making it compact for surface mount technology (SMT) applications.

This varistor covers an operating varistor voltage of 205 V with a maximum AC voltage rating of 130 V and DC voltage rating of 170 V. It withstands surge currents up to 400 A maximum and supports continuous operation in ambient temperatures ranging from -40°C up to 85°C.

Bourns PV130K3225R2 is offered in tape and reel packaging, facilitating high-volume automatic pick-and-place assembly. Its energy rating of 7 joules provides robust protection for sensitive electronic circuits against transient voltages caused by switching, lightning, or other electrical disturbances.

Ideal for industrial electronics, power supply units, and consumer electronics requiring surge protection in low to medium voltage ranges, this varistor enhances device reliability and longevity.

Designed for protection against voltage surges in low and medium voltage regions. Features non-flammable UL 94 V-0 rated thermoplastic encapsulation. Easily solderable with tinned copper sheet contacts. Operates continuously at temperatures up to 85°C.

Available in tape and reel packaging for automated assembly processes. Package size of 3225 suitable for surface mount technology. Energy rating of 7 joules for reliable surge absorption. Supports operating voltage range up to 205 V varistor voltage and peak maximum AC voltage of 130 V.
