Molex Micro-Fit 3.0 Series Straight Through Hole PCB Header 8 Contact 3 mm Pitch 2 Row Shrouded 43045-0828

Molex 43045-0828 Micro-Fit 3.0 Series Straight Through Hole PCB Header is engineered for robust wire-to-board connection applications requiring reliable performance. Featuring a 3 mm pitch and dual-row 8-contact design, this connector ensures compact integration even in tight spaces.

The housing material is high-quality thermoplastic, offering strong mechanical endurance and electrical insulation. Gold plating on the brass contacts provides enhanced conductivity and resistance against corrosion, ideal for long-term durability under demanding industrial conditions.

With a current rating of 8.5 amperes and a voltage rating of 600 volts, this PCB header accommodates substantial electrical loads. It operates effectively across a wide temperature range from -40°C to 125°C, making it suitable for industrial, electronic manufacturing, automotive, and consumer electronics sectors.

The connector is designed with a solder termination type and includes a tail pin length of 3.18 mm. Its male contact gender and shrouded design along with the PCB polarizing peg prevent errors during assembly and increase safety by reducing electrical shorts.

This product has no specific standards or approvals listed but includes glow-wire capability for enhanced flammability resistance.

Applications for this PCB header include power distribution, signal transmission, and modular electronic assemblies in commercial and industrial environments. It facilitates reliable and safe electrical connections between wire harnesses and printed circuit boards.

Constructed with thermoplastic housing providing durability and resistance. Features 2 rows with 8 circuits allowing compact and reliable connections. Gold-plated brass contacts ensure excellent electrical conductivity and corrosion resistance.

Operates within temperature range of -40°C to 125°C for industrial environments. Designed for solder termination with a tail pin length of 3.18 mm and a male contact gender. Supports a maximum current rating of 8.5 A and voltage of up to 600 V.

Includes a shrouded design with PCB polarizing peg to prevent mismating. Complies with glow-wire capability suitable for safety standards. Explore the Molex brand and Micro-Fit 3.0 series connectors on EnvMart for a comprehensive range of PCB Headers suited to various electronic assembly requirements.
