Samtec TSM Series Vertical Surface Pin Header 2 Contact 2.54 mm Pitch 1 Row Unshrouded TSM-102-02-T-SV

Samtec TSM-102-02-T-SV vertical surface pin header is a precision-engineered connector designed for electronics applications requiring reliable board-to-board interfacing. It features 2 contacts arranged in a single row with a 2.54 mm pitch, making it suitable for compact and dense PCB layouts.

The connector housing is made from black liquid crystal polymer, a material known for excellent thermal stability and mechanical strength, ensuring long-term performance under demanding conditions. The contacts are crafted from phosphor bronze, plated with gold to provide superior electrical conductivity and resistance to corrosion.

Rated for a current of 5.4 amperes and a voltage of up to 475 volts, this pin header supports medium-power electronic circuits. It operates efficiently within a temperature range from -55°C to 125°C, thereby offering versatility in various industrial, laboratory, manufacturing, and aerospace environments.

The unshrouded contact design facilitates easy soldering during PCB assembly and allows simple inspection and maintenance. This header is designed for vertical orientation and surface mounting, making it ideal for applications that demand secure mechanical and electrical connections with minimal board footprint.

Its solder termination type ensures compatibility with standard automated PCB soldering processes used in volume production. The product complies with RoHS standards, reflecting adherence to environmental and safety regulations.

Features a vertical orientation suitable for surface mount applications. Constructed with black liquid crystal polymer housing for high durability. Contacts made from phosphor bronze with gold plating for enhanced conductivity and corrosion resistance.

Supports current rating of 5.4 A and voltage up to 475 V. Operating temperature ranges from -55°C to 125°C ensuring suitability for harsh environments. Designed with 2 contacts arranged in a single row with a 2.54 mm pitch.

Unshrouded contact design offers accessibility for soldering and inspection. Termination type is solder, fitting standard PCB assembly processes. RoHS compliant, meeting environmental and safety standards. Compatible with board-to-board connector systems to facilitate compact electronic assemblies.

This Samtec TSM series pin header is ideal for use in industrial electronics assemblies, low to medium power electronic devices, communication equipment, measurement instruments, and other commercial or industrial electronic systems where reliable interconnections are critical.
