DiodesZetex Darlington Transistor PNP 2 A 120 V 3 W Power Dissipation SOT-223 FZT705TC

DiodesZetex FZT705TC is a PNP Darlington transistor engineered for high-gain switching and amplification in electronic circuits. Rated with a continuous collector current of 2 A and a collector emitter voltage of 120 V, it supports medium power applications requiring efficient thermal management up to 3 W power dissipation.

Packaged in a 4-pin SOT-223 surface mount form factor, this transistor is optimized for automated assembly in electronics manufacturing, ensuring compact design integration and space-saving on printed circuit boards (PCB).

The high minimum DC current gain (hFE) of 2000 allows for strong current amplification, making it ideal for driving loads in automotive, industrial, and consumer electronics sectors. It complies with AEC-Q101 automotive standards, suitable for demanding environments.

Operable in a wide temperature range from -55°C to 150°C, it guarantees reliable performance in harsh conditions. Electrical durability is enhanced by a maximum emitter base voltage of 10 V and a collector base voltage of up to 140 V, ensuring robust switching characteristics.

This transistor features a high minimum DC current gain of 2000. Surface mount package SOT-223 enables automated production efficiency. Rated for 2 A continuous collector current and 120 V collector emitter voltage. Maximum power dissipation is 3 W for reliable thermal performance.

Complies with automotive standard AEC-Q101 for quality assurance. Wide operating temperature from -55°C to 150°C enhances versatility. Compact dimensions of 6.7 mm length and 1.65 mm height support dense PCB layouts. Maximum collector emitter saturation voltage is -120 V for efficient conduction.

This Darlington PNP transistor is commonly used in electronic circuits requiring high current gain and switching efficiency in industrial, automotive, and laboratory electronic designs. It offers dependable operation in power management and signal amplification applications, suitable for discrete semiconductor device requirements.
