Nexperia 60 V 1.41 A Schottky Diode Single 2-Pin Surface Mount SOD-123W PMEG6010ELRX
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 2.8mm |
| Model | PMEG6010ELRX |
| Width | 1.9mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-123W |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1.41A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 300μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 660mV |
| Peak Reverse Recovery Time trr | 4.5ns |
| Average forward current | IF(AV) ≤ 1 A |
| Reverse voltage | VR ≤ 60 V |
Key Features
- This diode features extremely low leakage current, improving efficiency in power applications.
- The device has a low forward voltage of 660 mV, reducing power losses.
- Peak reverse recovery time is 4.5 ns, enabling high-speed switching.
- The diode supports a maximum operating temperature of 175°C, suitable for demanding environments.
- It is AEC-Q101 qualified, assuring automotive-grade reliability.
- The package is a small and flat Surface Mount Device (SMD) for space-saving PCB designs.
- This diode integrates a guard ring for stress protection enhancing durability.
- Peak reverse repetitive voltage is 60 V with a peak reverse current of 300 μA.
Product Description
The Nexperia PMEG6010ELRX is a medium power, low forward voltage Schottky diode with a maximum continuous forward current of 1.41 A and a reverse voltage rating of 60 V. It is housed in a compact SOD-123W plastic surface-mount package designed for space-saving on printed circuit boards.
This Schottky diode is engineered to extend battery life and improve power efficiency with very low leakage current and high-speed performance. Its peak reverse recovery time of 4.5 ns and low forward voltage of 660 mV contribute to increased efficiency in high-frequency switching applications.
Qualified to the AEC-Q101 automotive standard, the PMEG6010ELRX guarantees reliability under harsh temperature conditions, capable of operating up to 175°C.
The integrated guard ring offers enhanced protection against stress, improving durability in industrial, automotive, and consumer power supply applications. The device supports a peak reverse repetitive voltage of 60 V, peak reverse current of 300 μA, and a non-repetitive forward surge current up to 50 A.
Its compact dimensions (2.8 mm length, 1.9 mm width, 1.1 mm height) make it ideal for compact PCB designs in automotive electronics, power management circuits, and general industrial electronics. The package type SOD-123W facilitates efficient surface mounting and thermal dissipation.
Extremely low leakage current enhances power efficiency. Low forward voltage reduces power losses. Fast switching with 4.5 ns recovery time. High operating temperature of up to 175 °C. AEC-Q101 qualification for automotive reliability.
Small surface mount package for space savings. Integrated guard ring for stress protection. Robust peak surge current capability. Suits industrial, automotive, and consumer power applications. Compact size supports dense PCB layouts.
Discover more semiconductor components and advanced Schottky diodes in the Electronics & Electricals category at EnvMart for your industrial and commercial electronics projects.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this model is 1.41 A.
It has a peak reverse repetitive voltage rating of 60 V.
The maximum forward voltage drop is 660 mV.
The peak reverse recovery time is 4.5 ns.
The dimensions of the SOD-123W package are 2.8 mm in length, 1.9 mm in width, and 1.1 mm in height.
The maximum operating temperature is 175°C.
Yes, it is AEC-Q101 qualified, ensuring reliability for automotive applications.
The peak reverse current is rated at 300 μA.
This diode uses surface mounting (SMD) for installation.
The minimum operating temperature is -55°C.
The diode can handle a peak non-repetitive forward surge current of up to 50 A.
It is suitable for industrial, automotive, and consumer power supply applications.
