TDK Shielded Wirewound Surface Mount Inductor, Metallic Magnetic Core, 10μH ±20% Inductance, 3.6A Maximum DC SPM6530T-100M

TDK SPM6530T-100M is a magnetically shielded wirewound surface mount inductor optimized for power circuits requiring reliable inductance and current handling capabilities. Featuring a metallic magnetic core, this inductor offers a low-profile design with dimensions of 7.1 mm in length, 6.5 mm in depth, and 3 mm in height, making it suitable for compact electronic assemblies and high-density PCB layouts.

The device provides an inductance of 10 μH with a tolerance of ±20%, ensuring consistent and stable operation within power supply circuits and filtering applications. It can handle a maximum DC current of 3.6 Amperes which allows it to support moderate current loads while maintaining low DC resistance of 72.49 mΩ, contributing to efficient power management and reduced heat generation.

Designed with a molded coil construction, the SPM6530 series reduces hum noise compared to core-adhesive coils, enhancing signal integrity. Its magnetic shielding protects surrounding components from electromagnetic interference. The inductor is suitable for operation in harsh conditions with an operating temperature range from -40°C to 125°C, making it well-adapted for automotive and industrial electronics applications where thermal stability is critical.

This component utilizes a surface mount termination style to support automated placement and soldering techniques used in modern manufacturing, improving production efficiency. Being RoHS compliant, it adheres to regulatory requirements for hazardous substances, aligning with environmentally conscious manufacturing practices.

Typical applications include power supply filters, DC/DC converters, and computer motherboards where small size, low noise, and dependable inductance are essential. The SPM6530T-100M is part of the SPM series by TDK, known for high-performance inductors meeting stringent industrial standards.

Inductance: 10μH ±20% tolerance. Maximum DC Current: 3.6A. Package/Case: 6530 with low-profile dimensions. Shielding: Yes, magnetically shielded construction. Operating Temperature Range: -40°C to 125°C. Maximum DC Resistance: 72.49mΩ for efficient conduction.

Termination Style: Surface mount for modern assembly. Core Material: Metallic Magnetic for stability. RoHS Compliant ensuring environmental safety.

For buyers seeking high-quality, reliable Surface Mount Inductors for industrial, automotive, and power electronics applications, the TDK SPM6530T-100M delivers robust performance with compact size and shielding benefits. Explore similar inductors or other TDK components on EnvMart for complete solutions.
