TDK Shielded Wirewound Surface Mount Inductor, Ferrite Core, 10µH, ±20%, 3.9A, VLS6045EX-100M
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 6mm |
| Model | VLS6045EX-100M |
| Depth | 6mm |
| Series | VLS-EX |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 10μH |
| Standards/Approvals | RoHS |
| Package/Case | 6045 |
| Maximum DC Current | 3.9A |
| Pin Count | 2 |
| Maximum DC Resistance | 47mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Ferrite core construction provides high magnetic shielding and low electromagnetic interference.
- Wirewound surface mount design ensures compatibility with automated PCB assembly processes.
- 10µH inductance with ±20% tolerance supports filtering and energy storage applications.
- Rated for a maximum DC current of 3.9A for use in power supplies and DC-DC converters.
- Low DC resistance of 47mΩ for efficient power handling and reduced losses.
- Compact 6 mm x 6 mm footprint and 4.5 mm height for high-density board layouts.
- Operating temperature range from -40°C to 105°C for demanding environments.
- Ideally suited for TVs, game devices, set-top boxes, and audiovisual equipment.
Product Description
TDK VLS6045EX-100M is a shielded wirewound surface mount inductor designed for power circuit applications, offering superb performance and reliability in modern electronic devices. This inductor features a robust ferrite core and wirewound construction, delivering high magnetic shielding essential for minimizing electromagnetic interference in dense circuit layouts.
With an inductance value of 10µH and ±20% tolerance, the VLS6045EX-100M supports energy storage and filtering in power supplies, DC-DC converters, and a variety of industrial and consumer applications. The device handles a maximum DC current of 3.9A and offers a low maximum DC resistance of 47mΩ, ensuring high efficiency and low power loss in demanding conditions.
Ferrite core ensures powerful magnetic shielding, suitable for minimizing EMI in electronic circuits. Wirewound construction supports high current and low resistance, optimizing system performance. Standard 6045 SMD package with dimensions of 6 mm x 6 mm x 4.5 mm for compact assemblies.
Surface mount termination for compatibility with automated assembly lines and reflow soldering. Reliable performance across extended temperature range from -40°C to 105°C. Moulded body and shielded architecture enhance mechanical robustness and electrical performance.
RoHS compliant ensuring safe use in environmentally conscious designs. Designed for high-density mounting, supporting miniaturization and advanced electronics development.
Typical applications include use in televisions, audio visual devices, set-top boxes, game equipment, and other electronic assemblies where high current, low profile, and superior shielding are required.
This inductor’s rugged build and electrical characteristics make it well-suited for use in industrial, commercial, and advanced consumer electronics. Explore more TDK inductors and passive components in EnvMart’s Surface Mount Inductor category to meet your circuit design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 10µH with a tolerance of ±20%.
This inductor is rated for a maximum DC current of 3.9A, making it suitable for power supplies and DC-DC converters.
The dimensions of this model are 6 mm in length, 6 mm in depth, and 4.5 mm in height.
It operates within a temperature range of -40°C to 105°C, suitable for demanding environments.
The maximum DC resistance for this inductor is 47mΩ, which contributes to efficient power handling and reduced losses.
It features a wirewound construction with a ferrite core, providing high magnetic shielding and minimizing electromagnetic interference.
Yes, it is RoHS compliant, ensuring safe use in environmentally conscious designs.
This model uses a surface mount termination style, making it compatible with automated assembly processes.
It is ideally suited for use in televisions, game devices, set-top boxes, and audiovisual equipment.
The VLS6045EX-100M has a pin count of 2.
This model belongs to the VLS-EX series of inductors.
The ferrite core construction provides high magnetic shielding, which is essential for minimizing electromagnetic interference in dense circuit layouts.
